High Precision Sheet Metal Roll Forming Machines , Sheet Metal Roll Former

Brand Name	NFCase		Place of Origin	China
Model Number	AIA-1

Delivery Time:3-5 days
Certification:CE,FCC,MSDS

High Precision Sheet Metal Roll Forming Machines , Sheet Metal Roll Former

Cold Rolling Mills

?Feeding section with guide; ?Gear / Sprocket driving;23-step to form ?Rollers manufactured from 40Cr, CNC lathes, hard Chrome Coated ?Shafts Diameter=75mm, Precision Machined ?Main motor = 7.5 KW, Frequency speed control ?Forming speed: Approx. 15m/min; ?Protection Mesh Cover (full mesh type) Above Roll-former To Avoid Hands Go Inside

Machine composition

5Ton * 1250mm Hydraulic un-coiler Hydraulic system?expand?coil inner hole, Pump motor: 3KW Frequency Inverter to regulate turning speed, Motor:?2.2KW Link-connect expanding system Automatic stopping device, Load capacity = Max.5Tons Coil Inner-diameter= 510±30mm, Coil width = Max.1250mm Dance arm assistance for coil-turning speed control Manual Pre-shearing device (Un-powered) ??????????? Smart cut control, to cut off the end of the final piece of sheet onl

Hydraulic Cutting Device

Stop to cut, Post cut, No Blanking cut Pump motor =4.0KW Cutting tool material : Cr12, Heat treatment;

PLC Control System

Control the quantity & cutting length automatically; Combined with:?PLC, Touch Screen (SIEMENS), Inverter (SCHNEIDER),?Encoder (Omron), etc Cut-to-length tolerance≤±2 mm Control Voltage 24V Product Rack ?????Un-powered, 3 units

Refered Information

GI Corrugate Roof forming machine? material thickness:0.2mm? feeding width: 762 / 925mm?

Packaging & Delivery

Packaging Details	40HC\'*1
Delivery Detail	45 DAYS

Machine Shows

Workshop Show
