16 - 26 Stations Sheet Metal Roll Forming Machines with High Grade 45 # Steel

FOB Price

USD $4 - $5 / Piece

1 Piece(Min.Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	NFCase		Place of Origin	China
Model Number	AIA-1

Product Description

Delivery Time:3-5 days
Certification:CE,FCC,MSDS

16 - 26 Stations Sheet Metal Roll Forming Machines with High Grade 45 # Steel

Sheet Metal Cold Rolling Mills Introduction?

Coil Material ??? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ??	Thickness	0.8-1.5mm ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?
Coil width	Custom-made
Yield Strength	250-350Mpa
Material	PPGI, GI. ? ? ? ? ? ? ? ? ? ? ? ? ? ?
Decoiler / Uncoiler	Coil Width	Max. 1250mm
I.D	508-610mm
O.D	Max. 1500mm
Roll Forming ? ?Machine ? ? ? ? ? ? ? ? ? ? ? ?	Forming Stations	16-26?Stations ( Depend on Profiles ) ?
Roller material ?	45# steel, surface coated with 0.05mm ? ? ?hard chrome?? ? ? ? ? ? ?
Diameter of shaft	90mm
Shaft material	High grade 45# steel
Drive type	Chain transmission
Forming speed ? ??	0-15m/min
Main power	11KW X 2
Cutting	Cutting type	Hydraulic cutting
Cutting power	4KW
Cutting?Tolerance????	10m1.5mm
Encoder	OMRON Brand
Electrical control	PLC	PANASONIC Brand or Custom-made
Inverter	YASKAWA Brand or Custom-made
Touch screen	MCGS Brand?or Custom-made
Operation type	Touch screen & Button
Hydraulic Station	Hydraulic station	Famous Chinese brand
Runout Table	Table type	Simple nonpower type
Function	To support the finished panels

Hydraulic Cutting Device

Stop to cut, Post cut, No Blanking cut Pump motor =4.0KW Cutting tool material : Cr12, Heat treatment;

PLC Control System

Control the quantity & cutting length automatically; Combined with:?PLC, Touch Screen (SIEMENS), Inverter (SCHNEIDER),?Encoder (Omron), etc Cut-to-length tolerance≤±2 mm Control Voltage 24V Product Rack ?????Un-powered, 3 units

Machine Composition

5Ton * 1250mm Hydraulic un-coiler Hydraulic system?expand?coil inner hole, Pump motor: 3KW Frequency Inverter to regulate turning speed, Motor:?2.2KW Link-connect expanding system Automatic stopping device, Load capacity = Max.5Tons Coil Inner-diameter= 510±30mm, Coil width = Max.1250mm Dance arm assistance for coil-turning speed control Manual Pre-shearing device (Un-powered) ??????????? Smart cut control, to cut off the end of the final piece of sheet onl

Machine Shows

Mannul Decoiler?Show
