Building Material Corrugated Roof Sheet Making Machine Galvanized Steel Sheet
- T/T L/C D/P D/A
- 7 days
You May Like
-
Automatic Steel C Z Purline Roll Forming Machine Quick Change
-
Small Corrugated Sheet Metal Roof Roll Forming Machine / Roof Panel Making Machine
-
Galvanized Steel Roof Roll Forming Machine Roofing Sheet Production Machines
-
Wave Shape Roof Sheet Roll Forming Machine European Standard
-
16 - 26 Stations Sheet Metal Roll Forming Machines With High Grade 45 # Steel
-
Computer Controled Metal Forming Machinery For Roller Shutter Door
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
Building Material Corrugated Roof Sheet Making Machine Galvanized Steel Sheet
Material of Main Equipment
|
Roller Material:high grade No.45 forged steel, plated hard chrome on the surface of roller with thickness 0.05mm? |
Active Shaft Material?: high grade No.45 carbon wrought steel at Φ 75mm.
Cutter Blade?: Cr12 mould steel with quenched treatment.
Electric Elements :TP170, Siemens. It can input 10sets of spec at one time
Oil Tank Model:CB-E310
Product Description
Corrugated roof roll forming machine?consists of uncoiler and its base, coil sheet?guiding?equipment, film ? covered device, roll forming system,
post-cutting equipment,hydraulic station, controlling system, supporter table.?
?Technical parameters
1) Material spec: colored steel sheet; galvanized steel sheet
2) Thickness of coil sheet: 0.2 - 0.7 mm
3) Main motor power: 4~5.5KW
4) Forming speed: 8-12m/min
5) Hydraulic station power: 3KW
6) Quantity of stands: about 17 groups
7) Hydraulic pressure: 10 - 12MPa
8) Controlling system: PLC
9) Index error of length: 10m±2mm
10) Total weight: about 1,000kg
11) Voltage: 380V 3 phase 60Hz or at buyer\'s requirement
?Working Flow
Decoiling?the?sheet------Sheet?guiding------Roll?forming------Pressing?the?panel------Measure?length------ ? ? Cutting?the?panel------Panels?to?the?supporter?
?Machinery?Shows
?Office Show
Why choose us?
1. Accomplishment
? ? Shanghai Allstar Company have the strong technician team to serve our customer. We have successfully serve many domestic customers in the past.
2. High quality
? ? The zinc roof panel roll forming machine main parts are imported from famous factory in the world. Such as Siemens ; Delixi ; OMRON and etc.
3. Competitive price
? ? Our zinc roof sheet roll forming machine with competitive price because of the advance technology. So we are the best partner for you to choose !
4. Innovation
? ? Our team developed the new solutions for different customers of different requirements.
5. Visit
? ? Whenever you come to visit our factory, you can see cold roll forming machinemachine?in our factory. wait for your contact.
Contact Us
- Wuxi Shenghong Machinery Co.,ltd
- Contact nameMs. Tong Chat Now
- Phone86-510-88159551
- AddressNo 113, xixian road, high tech park, Liaocheng, Shandong
