Petroleum Industry Welding Column and Boom Full-Automatic for Pipe Rotation Welding Station
Negotiable
/ Set
1 Set(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Motorized Movable Column and Boom Welding Manipulators 6 * 6m For SAW Welding
-
Automatic Pipe Welding Manipulator Heavy Duty Type for Large Welding Center
-
Fixed Vessel Fit Up Welding Manipulator 8 * 8m Automated Welding Equipment With Trolley
-
Heavy Duty Welding Column and Boom For Steel Pipe / Tank Welding 8000 * 8000mm
-
High Efficiency Welding Column and Boom Manipulator for Vessel Longitudinal Seam Welding
-
Pipe Rotating Automatic Welding Manipulators 2 * 2m for Circle Seam Welding
Product Details
| Brand Name | H-WELDING | Place of Origin | China | |
| Model Number | LH6060 |
Product Description
Certification:CE
Petroleum Industry LH6060 Welding Manipulator For Full-Automatic Pipe Rotation Welding Station
Specifications:
1-trolley ,2-column revolve unit,3-column,4-flux feeding and recovery system ,5-guide saddle,6-elevating unit,7-boom,8-welding system
|
Technical parameter |
LHZ4040 |
LHZ5050 |
LHZ6060 |
LHZ7070 |
|
Elevating stroke mm |
4000 |
5000 |
6000 |
7000 |
|
Retracting stroke mm |
4000 |
5000 |
6000 |
7000 |
|
Elevating speed mm/min |
1000 |
|||
|
Retracting speed mm/min |
120-1200 |
|||
|
Minimum distance between boom and track surface mm |
1110 movable with revolve/950 stationary with revolve |
1180movable with revolve/1170 stationary with revolve |
||
|
Boom end maximum weight loading kg |
120 |
200 |
||
|
Column revolving |
Angle |
＋180o |
||
|
Speed rpm |
0.36rpm/or by manual |
|||
|
Trolley traveling speed mm/min |
1700 |
2500 |
||
|
Inner span of trolley rail mm |
1730 |
2000 |
Description:
With 100×100mm precise motorized cross slide unit, maximum loading 80kg; Adopt remote panel for operation, the cable for operate panel is imported from German.Applications:
Pipe fit up Tank produce line Welding centerCompetitive Advantage:
The trolley movement is driven by reducer through motor. The travelling speed is? 2000mm/min. Four rollers will drive together, moving placidly, There are anti- incline device at the end side of trolley, to ensure the safe and reliable during moving.Contact Us
