Galvanized steel sheet Roofing / Floor Deck Roll Forming Machine 15m/min

FOB Price

US$ 35000$ - 45000$ / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	ZOOY		Place of Origin	China
Model Number	ZO-DE55

Product Description

Delivery Time:60days after get 30% down payment
Certification:CE

Metal Deck Roll Forming Machine For 0.8 - 1.2mm Thickness, For Metal Decking, Roofing

Composition of machine

1. Roll forming main machine……………………………1 unit

2. 5 Tons Automatic de-coiler………………………… 1 unit

3. Control panel…………………………………………..1 unit

4. Hydraulic station………………………………………1 unit

5. 3 meters out table……………………… …….....1 unit

Main Specifications ??
?

Coil Material?	Thickness	0.8-1.6mm
Coil width	Depend on customer’s requires
Yield Strength	360N/mm2
Material	Galvanized steel sheet
Decoiler / Uncoiler	Coil Width??????????????????	Max. 1500mm
I.D	510-610mm
O.D	Max. 1300mm
Capability	Max.?5 Tons
Decoiler type	Manual / Hydraulic/Automatic
Feeding & Leveling	Pinch feeding	1?Units (?2 Rollers )
Cutting device	Cutting motion	Hydraulic Cutting, post-Cutting ( cutting sheet after forming )
Cutting blades	Cr12Mov with heat treatment HRC58-62
Length Measuring	Automatic length measuring by encoder & PLC.
Cutting Tolerance	1.5mm(per 3m)
Roll Forming?Machine	Forming Stations	24 Stations
Press Roller	One station press roller to make pressing for profile
Rectifying	1 unit
Roller material	GCr15 steel, heat treatment
Diameter of shaft	80mm
Shaft material	High grade 45# steel
Drive type	Chains
Forming speed	15m/min
Main power	22KW(11kw *2)
Servo motor	1 Units
Driven System	Driven by Motor	Transmission by chains
Electrical control	PLC	PANASONIC Brand or Custom-made
Inverter	YASKAWA Brand or Custom-made
Touch screen	MCGS Brand?or Custom-made
Operation type	Touch screen & Button
Hydraulic Station	Hydraulic station	Famous Chinese brand
Hydraulic power	7.5KW
Runout Table	Table type	Simple non-power type
Function	To support the finished panels
TOTAL WEIGHT	?	APRRO?8 TONS

The type pursues board (basis on customer\'s requires to design)??????
?

Competitive Advantage:

Economical Simple Standard speed High Quality Reliable Durable Reasonable Price Good after Service 1 Year Warranty More Than 10Years Experience

.
Guarantee:
1: Guaranteed against malfunctions due to manufacturing defects for 1 year after date of purchase. Repairs will be made free of charge.
2: Reparis will not be performed free of change even during the guarantee period in the follow circumstances
-? damage occurs due to a natural disaster
- ?malfunction occurs due to user error
-? malfunction occurs due to modifications
-? m
