fully Automatic Floor Metal Deck Roll Forming Machine 15m/min G250 - 350MPA
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
professional Aluminum / Color Steel Roof Tile Roll Forming Machine with Hydraulic Cutting
-
Galvanized steel roofing sheet roll forming machine corrugated Cold Roll Former
-
Grain Panel Silo Making Machine roller forming machine with Hydraulic station
-
Corrugated Silo Making Machine Cold Roll Former 0-15m/min 2.0-4.0mm Thickness
-
Galvanized Steel Wall Panel Continuous Pu Sandwich Panel Production Line 2-5m/min
-
OR wall / Ceiling PU Sandwich Panel Machine Production Line with Aluminum Foil Facing
Product Details
| Brand Name | ZOOY | Place of Origin | China | |
| Model Number | ZO-DE51 |
Product Description
Certification:CE
G250 - 350MPA Metal Deck Roll Forming Machine For 0.8 - 1.6mm Thickness, For Metal Decking, Roofing
Composition of machine
1. Roll forming main machine……………………………1 unit
2. 5Tons Automatic de-coiler………………………… 1 unit
3. Control panel…………………………………………..1 unit
4. Hydraulic station………………………………………1 unit
5. 3 meters out table……………………… …….....1 unit
Main Specifications ??
?
|
Coil Material? |
Thickness |
0.8-1.6mm |
|
Coil width |
Depend on customer’s requires |
|
|
Yield Strength |
360N/mm2 |
|
|
Material |
Galvanized steel sheet |
|
|
Decoiler / Uncoiler |
Coil Width???????????????? |
Max. 1500mm |
|
I.D |
510-610mm |
|
|
O.D |
Max. 1300mm |
|
|
Capability |
Max.?5 Tons |
|
|
Decoiler type |
Manual / Hydraulic/Automatic |
|
|
Feeding & Leveling |
Pinch feeding |
1?Units (?2 Rollers ) |
|
Cutting device |
Cutting motion |
Hydraulic Cutting, post-Cutting ( cutting sheet after forming ) |
|
Cutting blades |
Cr12Mov with heat treatment HRC58-62 |
|
|
Length Measuring |
Automatic length measuring by encoder & PLC. |
|
|
Cutting Tolerance |
1.5mm(per 3m) |
|
|
Roll Forming?Machine |
Forming Stations |
24 Stations |
|
Press Roller |
One station press roller to make pressing for profile |
|
|
Rectifying |
1 unit |
|
|
Roller material |
GCr15 steel, heat treatment |
|
|
Diameter of shaft |
80mm |
|
|
Shaft material |
High grade 45# steel |
|
|
Drive type |
Chains |
|
|
Forming speed |
15m/min |
|
|
Main power |
22KW(11kw *2) |
|
|
Servo motor |
1 Units |
|
|
Driven System |
Driven by Motor |
Transmission by chains |
|
Electrical control |
PLC |
PANASONIC Brand or Custom-made |
|
Inverter |
YASKAWA Brand or Custom-made |
|
|
Touch screen |
MCGS Brand?or Custom-made |
|
|
Operation type |
Touch screen & Button |
|
|
Hydraulic Station |
Hydraulic station |
Famous Chinese brand |
|
Hydraulic power |
7.5KW |
|
|
Runout Table |
Table type |
Simple non-power type |
|
Function |
To support the finished panels |
|
|
TOTAL WEIGHT |
? |
APRRO?8 TONS |
The type pursues board (basis on customer\'s requires to design)??????
?
Competitive Advantage:
Economical Simple Standard speed High Quality Reliable Durable Reasonable Price Good after Service 1 Year Warranty More Than 10Years Experience.
Guarantee:
1:Guaranteed against malfunctions due to manufacturing defects for 1 year after date of purchase. Repairs will be made free of charge.
2:Reparis will not be performed free of change even during the guarantee period in the follow circumstances
-? damage occurs due to a natural disaster
- ?malfunction occurs due to user error
-? malfunction occurs due to modifications
