High Light Efficiency Outdoor LED Street Light 135-155lm/w Led Street Light Module 20W - 30W

Brand Name	Lepower		Place of Origin	China
Model Number	CHEM 20W

Delivery Time:5-10 days
Certification:CE,Energy Star,FCC,RoHS
? Customized Outdoor LED Street Lights 135-155lm/w Led Street Light Module 20W - 30W

Quick Detail:

Item Type: Street Lights LED Light Source: Bridgelux LED Input Voltage(V): 29-32V Lamp Power(W): 20-30W Lamp Luminous Flux(lm): 4500 Lamp Luminous Efficiency(lm/w): 150LM/W CRI (Ra>): 50 Color Temperature(CCT): 4500-5200K Working Temperature(℃): -20 - 60 Working Lifetime(Hour): 50000 Lamp Body Material: Aluminum IP Rating: IP68 Certification: CE,FCC,RoHS Place of Origin: Guangdong, China (Mainland) Brand Name: Lepower Model Number: CHEM 20W Warranty(Years): 5

Description:

20-30W different power customized Convection heat radiation design, deduce light decay and prelong life span, CHEM module, easy replacing.High luminous efficiency 20PCS Bridgelux LED inside,High efficiency. Adoption Lepower exclusive ZAG lens with high light transmittance up to 98%,No glare,No RF interference. Excellent heat dissipation design. Easy to assemble and costs less for replacing. Total Lumen 3400-4500LM,lumens efficiency is up to 150/W.. Convection heat dissipation system ensure LED long life span. Several led chips available, easy selection with your goal. Unique aluminium heatsink greatly reduce product weight and guarantee the safety usage, This new heatsink significantly increase the efficiency of thermal conduction with less material usage and more saving on energy. It is the best solution of LED street light.

Applications:.

Widely used in billboards, highways, railway tunnels, bridges, squares, stadiums, parking lots, building walls,factories and so on

Specifications:

Model	CHEM 20W
LED Qty	20pcs
LED Type	Bridgelux
LED Power	20W/30W
LED Color	White
Input Voltage	AC85~265V
Frequency Range	50Hz – 60Hz
Power Factor	>98
Power Efficiency	>85%
Luminous Efficiency	150~160LM/W
Color Temperature	WW	2800-3000K
PW	3500-4000K
CW	4500-5200K
CRI	WW	Ra>45
PW	Ra>50
CW	Ra>70
Lamp Efficiency	>85%
Lumens Output	WW	3000-4800lm
PW	3000-4800lm
CW	3000-4500lm
Beam Angle	75*152
Working Temperature	-20℃ ～ +40℃
Storage Temperature	-40℃ ～ +100℃(25℃best)
Life span	>50000hrs
Certification	CE,FCC,RoHS
Housing Color	silvery white

1. Open the packaging, check the products carefully, and take them gently. 2. Installation and removal products, please disconnect the light\'s power to avoid the risk of electric shock.

Competitive Advantage:

Match with Lepower exclusive lens, light transmittance rate can be up to 92% Super high light efficiency, up to 150lm/W Exclusive products with national patent High quality materials ensure super quality Super high lumens light source,Bridgelux chip. New heatsink significantly increase the efficiency of thermal conduction with less material usage and more saving on energy. It is the best solution of LED street light.
