4 in 1 Full Automatic Bottle Filling Machine 4000BPH For PET Bottle

Brand Name	Jiayuan		Place of Origin	China
Model Number	CGF16-16-12-6

Delivery Time:30 days
Certification:CE,SGS

4 in 1 Full Automatic Bottle Filling Machine 4000BPH For PET Bottle

Quick Detail:

Capacity: 4000 bottles per hour Sterilizing water rinser, pure water rinser, filler, capper 4-in-1 monoblock Fully automatic, no bottle no filling, no cap machine will stop. CE, ISO certificate Designed power supply: AC/380V/50HZ/3PHASE Customizable

Automatic SUS304/316 4000BPH CGF16-16-12-6 4-in-1 bottle water machine

Description:

(1)The?4-in-1 bottle water machine?is mainly used in the pure water, mineral water filling operations. The three functions of bottle wash fill and seal are composed in one body of the machine. The whole process is automatic.? The first rinsing machine is medical water rinsing machine, the second rinsing machine is purified water rinsing machine. The bottle will be cleared and sterilized after the two rinsing machine.

(2)The bottle water machine is used in filling mineral water or pure water in bottles made of polyester and plastics. The machine can also be used in hot filling if being installed with temperature controlling device. The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles.?

(3)The filling operation is faster and more stable because the micro pressure filling operation of the new type is adopted. There the output and benefit of the machine is higher than the machinery of the same specifications.?

(4)The advanced OMRON programmed controller (PLC) is adopted to control the machine to run automatically while a transducer is used in the bottle -entering chains to adjust speeds and coordinated with the transducer of the main machine to make the operations of moving bottle forward steadily and reliably.?

(5)It is convenient to operate with higher automation because every part of the machine is inspected to run with photo electricity, on the bases, the filling parts of the machine can be changed into filling methods of lower vacuum.?

(6)The filling category of lower vacuum (Z type machine) is applicable in glass bottles, filling alcohol, soy and such like materials. The aluminum theft proof cap and plastic cap can be adopted. The machine is idea-preferred equipment for beverage maker

Application

This bottle water machine can be used for filling non-carbonated liquid beverage with normal or middle temperature into PET bottles and capping it automatically.

Pure water Mineral water Juice filling with normal temperature or middle temperature.

Specifications:

Model:	CGF16-16-12-6
Capacity:500ml(b/h)	2000-4000
Suitable Bottle Height(mm)	130-280
Suitable Bottle Body Diameter(mm)	Φ40-φ80
Suitable Cap Shape	Plastic Screw Cap
Power: (W)	4.23
Filling Temperature:	Room Temperature
Water Consumption for Washing Bottle(kg/hr)	800
Gas Consumption(m3/min)	0.3
Size L×W×H (mm)	2100×1500×2200
Total Weight:(kg)	2000
Power Supply	380V/50HZ

Competitive Advantage:

?

The?three?functions?of?bottle?washing,?filing?and?capping?are?composed?in?one?body?of?the?machine. The?whole?process?is?automatic, no bottle no filling, no cap, machine will stop. So?this?machine?has?three?steps,?first?is?washing,?second?is?filling,?third?is?sealing?the?bottle.? Low?power?consumption,?better?material?SUS?304,?SUS?316. Small?size, simple?structure, low?investment Auto?complete?line,?need?less?worker.
