Fully Automatic Juice Filling Machine 4000BPH For Round PET Bottle

Brand Name	Jiayuan		Place of Origin	China
Model Number	RCGF16-12-6

Delivery Time:30 days
Certification:CE,SGS

Fully Automatic Juice Filling Machine 4000BPH For Round PET Bottle

Quick Detail:

Model: RCGF16-12-6 Capacity: 2000-4000BPH@0.5L bottle Seller: Jiayuan Application: Juice, energy drink, tea beverage etc. hot filling. Easy operate for changing different bottle volume. Designed applicable bottle: 0.2L-2L round PET bottle Designed applicable cap: plastic screw cap. Full automatic, No bottle no filling, No cap machine stop. CE & SGS Certificate Customizable 1 Year warranty Orange juice machine

Automatic SS304/316 4000BPH RCGF16-12-6 Orange juice machine RFC 3-in-1 Monoblock Hot Filling Machine

Description:

1. High efficient hot filling machine/filler range from 1000bph to 20000bph, can apply to juice, tea, sport drinks, function drinks, etc.?

2. Rinsing/Filling/Capping 3-in-1 Monoblock?

Size of bottle: 200ml-2000ml round PET bottle.?

Cap type: 28~38mm standard plastic screw caps?
Method of bottle transferring: By holding neck?
Products: Tea/juice/energy drink/milk beverage.?

Structure:?

-Base?

-Rinsing part

-Filling part
-Capping part

(1). Rinsing part

Rotative rinsing turret one treatment, fixed nozzles, with grippers.?
The grippers take the bottles from the inlet starwheel while they are still driven by the starwheel, thus guaranteeing a safe grip.?
After the gripping, the bottle is turned upside down and centred above a spraying nozzle which directs a stream of rinse water into the bottle. After the draining period the bottle is turned over to an upright position again.?

?(2). Filling part

The starwheel drive the bottles always \"by holding bottle neck\" through the rinsing, filling and capping steps. For different types of bottle, it is easy to adjust the structure by our specialized design.?
Product bowl can reduce the loss of heat.?If the temperature is low than the setting value, the filling valves will stop and return the last beverage in filling valve to recirculation tank and be pumped return to UHT again to be sterilized and heated.?

(3). Capping part

Rotative capping turret, suitable to the application of plastic screw caps on PET bottles?

The fixed part consists of the cap-sorting bowl, the cap feeding elevator with relevant motor and the cam actuating the capping heads.?

The heads are raised and lowered by the action of a follower that is riding on a shaped cam.?

Applications:

1. Pure water/mineral water/portable water

2. Energy drink

3. Tea beverage

4. Juice filling with normal(20-30℃), middle(50-60℃) or high temperature(85-95℃)

Specifications:

Model	RCGF16-12-6
Capacity:500ml	2000-4000b/h
Suitable Bottle:	Height: 150-310(mm) Diameter: φ50-φ92(mm)
Suitable Cap:	Plastic Screw Cap
Filling Pressure:	0.6Mpa
Power	5.88kw
Size	2400×1670×2350mm
Weight	2500kg

Competitive Advantage:

Reasonable structured storage hopper and material supply system make the material in constant flow speed, constant pressure without frothing. Usually high position tank is adopted. Full filling to avoid the liquid level from sinking after the bottle cooling down, and to decrease the dissolved oxygen to the utmost extent. The storage hopper has the characteristic of gas discharge, full sealing and temperature detecting. In moderate and high speed production line, the material distributor replaces the big liquid tank to realize the complete CIP. Sanitary filling head system is of umbrella structure, high filling speed. Recirculation tank system has the function of supplying the material automatically. Perfect filling temperature control system. Perfect CIP system.
