0.85KW 200V Water Cooled CNC Spindle Compatible ABL H516D / WW D1722
- 0 Meter / Meters per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
180000 RPM Precision Machining High Frequency Spindles CNC Multi Spindle
-
Small Precision Electric PCB Drilling Spindle Water Cooled CNC Spindle
-
0.75KW PCB Drilling Spindle Cnc Router Motor Spindle 6.35mm - 0.05mm
-
Low Dynamic High Frequency Air Bearing Spindle ABL H920B 200000RPM
-
Westwind High Frequency Spindle Shafts High Precision Spindle Shaft D1264-07
-
PCB Drilling / Routing 125000 rpm Spindle Shafts Westwind D1331-17
Product Details
Brand Name | KLKJ | Place of Origin | China | |
Model Number | KL161 |
Product Description
Certification:ISO9001:2008
Compatible ABL H516D WW D1722 160,000RPM KL161D PCB Drilling Spindle?
Quick Detail:
MODEL |
REPLACE FOR |
DESCRIPTION |
KEY PRECISION |
Machine reference |
KL161D |
H516D D1722 |
SPEED RANGE:20,000 - 160,000 rpm ?6.35mm-0.05mm precision drilling |
Static Runout:<2μm Dynamic Runout:<7μm Vibration:1.0MM/S |
KLINGINBERG PLURITEC HITACHI LENZ ANDERSON …. |
PRODUCT DESCRIPTION
KL161D high frequency?spindle replace for ABL H516D or WW D1722 Full Range from 20,000 to 160,000 rpm, air bearing type in long life, spindle weight 4.1kg with COLLET size ?1/8 and body size ? 61.9, and FREQUENCY (HZ) is from 334-2760, SENSOR or Without For Choose.
Max power:0.85KW
Coolant:Water oil
Fixed voltage:200V
Fixed current:4A
Static Runout:<2μm
Dynamic Runout:<7μm
Vibration:1.0MM/S
Competitive Advantage:
Low Static
Low Dynamic RUN OUT
Stable character and long life
Suitable for precision drilling
Air bearing type offer Greater Precision, High Speed , Increased Tool Life, Improved Surface Finish, Long Bearing Life, Low Thermal Growth, Lack of Maintenance, Large Load Capacity , Reduced Vibration , Cleanliness.
APPLICATION :
PRINT CIRCUIT BOARD PRECISION DRILLING
HOLE RANGE: ?6.35mm-0.05mm
MACHINE REFERENCE:KLINGINBERG PLURITEC ;HITACHI ;LENZ ;ANDERSON ….
SPECIFICATION:
Air Pressure |
6.0 kgf/cm2 |
Coolant water temperature |
20+2 |
Static runout |
<2μm |
Dynamic runout |
<7μm |
Collet torque(N.cm) |
>=150( 1/8”) |
Vibration |
1.0MM/S |
Collet size |
?1/8” |
Temperature sensor ohms KΩ |
R=0.1±5% AT 25℃ |
Open air pressure |
?????????????????????????<5 kg/cm2 |
Close air pressure |
>2 kg/cm2 |
Coolant water flux |
>1.5(L/min) |
Coolant oil flux |
>3.0(L/min) |
Air consume flux |
74(L/min) |
Radial load |
6.0kgf |
Air Pressure |
6.0 kgf/cm2 |
???????????????????????????????? KL161 SPINDLE OUTLINE DRAWING
Why choose KLKJ?
With nearly 15 years technology in spindle maintenance, 10 years success experience for spindles parts production, and 9 years spindle R&D, KLKJ succeed in offer air bearing spindle up to 200krpm.
All spindles at the KLKJ are fully checked and tested using stringent quality control procedures. KLKJ ensures every repaired spindle passes the following points to make it in long life and stable character:
1.???? Air flow
2.???? Water flow
3.???? End float/lift off
4.???? Axial load (inner)
5.???? Axial load (outer)
6.???? Torque
? ? ? ? 7.? Static RUNOUT
? ? ? ? 8.? Dynamic RUNOUT
? ? ? ? 9.? Motor check
? ? ? ?10. Vibration
? ? ? 11. Material analysis & strictly quality test detection control
? ? ? 12. Stringent tolerance control?
