High Frequency 200000RPM Electric PCB Drilling Spindle ABL H920B
- 0 Kilogram / Kilograms per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
0.85KW 200V Water Cooled CNC Spindle Compatible ABL H516D / WW D1722
-
180000 RPM Precision Machining High Frequency Spindles CNC Multi Spindle
-
Small Precision Electric PCB Drilling Spindle Water Cooled CNC Spindle
-
0.75KW PCB Drilling Spindle Cnc Router Motor Spindle 6.35mm - 0.05mm
-
Low Dynamic High Frequency Air Bearing Spindle ABL H920B 200000RPM
-
Westwind High Frequency Spindle Shafts High Precision Spindle Shaft D1264-07
Product Details
| Brand Name | KLKJ | Place of Origin | China | |
| Model Number | KL200B |
Product Description
Certification:ISO9001:2008
?
?
Compatible ABL H920B 200,000RPM KL200B PCB Drilling Spindle
?
?
Quick Detail:
?
MODEL | REPLACE FOR | DESCRIPTION | Machine reference |
KL200B | H920B | ?6.35mm-0.05mm precision drilling | KLINGINBERG PLURITEC HITACHI LENZ ANDERSON …. |
?
?
?
PRODUCT DESCRIPTION
?
KL200B high frequency?spindle replace for ABL H920B Full Range from 20,000 to 200,000 rpm, air bearing type in long life, spindle weight 3.5kg with COLLET size ?1/8” and body size ? 61.9
?
Static Runout:<2μm
Dynamic Runout:<7μm
Max axial load:200N
Vibration:0.8MM/S
?
Competitive Advantage:
?
Low Static
Low Dynamic RUN OUT
Stable character and long life
Suitable for precision drilling
Air bearing type offer Greater Precision, High Speed , Increased Tool Life, Improved Surface Finish, Long Bearing Life, Low Thermal Growth, Lack of Maintenance, Large Load Capacity , Reduced Vibration , Cleanliness
APPLICATION :
?
PRINT CIRCUIT BOARD PRECISION DRILLING
HOLE RANGE: ?6.35mm-0.05mm
MACHINE REFERENCE:KLINGINBERG PLURITEC ；HITACHI ；LENZ ；ANDERSON ….
?
SPECIFICATION:
?
Speed range | 20,000 - 200,000 rpm |
Air Pressure | 6.0 kgf/cm2 |
Max power | 0.85KW |
Coolant | Water oil |
Coolant water temperature | 20+2 |
Fixed voltage | 200V |
Fixed current | 3A |
Static runout | <2μm |
Dynamic runout | <7μm |
Max axial load | 200N |
Spindle weight | 3.5kg |
Vibration | 0.8MM/S |
Temperature sensor ohms KΩ | R=10±3% AT 25℃ |
?
?
?
?
? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? Compatible H920B 200,000RPM 200B Spindle drawing
?
? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?Comment From Customer
