Automatic Commutator Turning Machine With Mechanical Arm And Conveyor

Specifications :

?
Description:
?
This machine is suitable for turning commutator. With advanced design, good shape and high performance, this machine adopts servo control for cutter moving and turning. Mechanical parts are imported, thus the machine is high efficiency and strong reliability.
The cutter moving in axial or radial direction is controlled by ball screws which are driven by three spindle servo motor. Turning times(4 times total) and cutter feeding value(≥1um) could be set up on touch screen according to user’s requirement. Three spindle servo motor controlling ensures the stable and precise cutter feeding.
Servo motor drives the belt rotating, meanwhile, the friction of flat belt and rotor surface make the rotor shaft high speed rotating on V block. Equipped with lubrication device and aluminum alloy frame, this machine features advance technology and modern shape, has easy operation system and self-checking system.
Meanwhile, equipped with an automatic feeding device and mechanical arm, this machine can achieve a fully automatic operation.
?
Applications:?
This machine is suitable for commutator fusing, it’s widely used in the motor field, such as wiper motor, vacuum cleaner motor, mixer motor, window lifter motor, condenser motor, power tool motor, DC motor, etc.
This machine is suitable for armature within the specification of the below table.
?
Competitive advantages:
Equipped with an automatic feeding device and mechanical arm, this machine can achieve a fully automatic operation.?Meanwhile, equipped with lubrication device and aluminum alloy frame, this machine features advance technology and modern shape, has easy operation system and self-checking system.
