Single Head Horizontal Self-suction Cosmetic Filling Machine For Ointment / Liquid

Single Head Horizontal Self-suction Cosmetic Filling Machine For Ointment / Liquid

Technical?Parameter:

Model???????filling?volume?????Air?consumption???????Net?weight?????????????Dimensions(mm)

LH-1-15?????5-150ml???????????23L/min?????????????????????11kg??????????????L92xW28xH40

LH-1-25??????10-250ml?????????30L/min????????????????????25kg??????????????L102xW30xH40

LH-1-50??????10-250ml?????????44L/min????????????????????28kg??????????????L108xW32xH41

LH-1-100?????60-1000ml????????87L/min??????????????????36kg??????????????L128xW36xH41

LH-1-250?????250-2500ml??????160L/min???????????????60kg??????????????L130xW60xH51

LH-1-500?????500-5000ml??????300L/min??????????????75kg??????????????L130xW60xH51

Description:

The horizontal self-suction liquid filling machine is suitable for filling products of various viscosity such as water injection and ointment etc. It is applied in such industries as daily chemical industry, pharmacy, food and pesticide etc. The semi-automatic piston type filling machine(full-pneumatic) is a new generation product developed on the basis of the original electric combined machines. It adopts pneumatic components to replace the electric control circuit. Therefore, it is especially suitable for use in damp conditions or conditions with explosion-proof requirements. The parts of our LM series products that contact materials are all made of imported 316L stainless steel and are machined through CNC machine tools with the surface roughness lower than 0.8.
?
The full-pneumatic filling machine can be classified into elaborate type (T type) product and ordinary type (P type) product. The elaborate type adopts Germany FESTO pneumatic components. The imported components of excellent quality has ensured its absolute leading position among other same machines in the country. The ordinary type selects pneumatic components from Taiwan or Korea. The good performance-price ratio enables more customers to experience the outstanding quality of LM series machines

Advantage:

One year warranty since the date of delivery, If any wearing part be broken within the warranty and not caused by improperly operation, the Seller would offer the new parts for free in the warranty perieod . and the whole machine is the maintanance of life.
