GR-1209-CORE / GR-1221-CORE High Stability 1* N PLC Bare Fiber Optic Cable Splitters
- T/T L/C D/P D/A
- 7 days
You May Like
-
Low PDL 1260 - 1650nm Fiber Optic Splitter PLC 1 * N Module With ABS Box For FTTX / PON
-
Dome 4 In-Outlet Port Fiber Optic Splice Closures With Max 48 Cores 288mm * 178mm
-
72 Cores Dome Fiber Splice Closure With 4 Inlet / Outlet Port 435 * 190 mm
-
590 * 320 * 215 mm 216 Cores Horizontal Fiber Optic Splice Closure With 8 In - Outlet Port
-
396 * 190 * 126 mm Horizontal Fiber Optic Closure With 6 In / Outlet Port , 72 Cores
-
455 * 220 *132 mm 96 Cores Horizontal Fiber Optic Splice Enclosure With 6 In / Outlet Port
Product Details
| Brand Name | Rollball | Place of Origin | China | |
Product Description
Certification:RoHS
GR-1209-CORE /? GR-1221-CORE High Stability 1* N PLC? Bare Fiber Optic Cable Splitter
Features
l?Low?Insertion?loss
l?Low?PDL
l?Compact?Design?
l?Good?channel-to-channel?uniformity
l?Wide?Operating?Wavelength:
???????From?1260nm?to?1650nm
l?Wide?Operating?Temperature:
???????From?-40℃?to?85℃
l?High?Reliability?and?Stability
Description
Planar?lightwave?circuit?(PLC)?splitter?is?a?type?of?optical?power?management?device?that?is?fabricated?using?
silica?optical?waveguide?technology.?It?features?small?size,?high?reliability,?wide?operating?wavelength?range?
and?good?channel-to-channel?uniformity,?and?is?widely?used?in?PON?networks?to?realize?optical?signal?
power?splitting.?Rollball?provides?whole?series?of?1xN?and?2xN?splitter?products?that?are?tailored?for?specific?
applications.?All?products?meet?GR-1209-CORE?and?GR-1221-CORE?requirements.
Applications
l?FTTX?Systems
l?PON?Networks
l?CATV?Links
l?Optical?Signal?Distribution
Compliance
l?Telcordia?GR-1209-CORE
l?Telcordia?GR-1221-CORE
l?RoHS
Specifications
Table?1?–?1×N?PLC?Splitter
|
Parameters |
1×2 |
1×4 |
1×8 |
1×16 |
1×32 |
1×64 |
|
Operating?Wavelength?(nm) |
?1260～1650 |
|||||
|
Fiber?Type |
SMF-28e?or?customer?specified? |
|||||
|
Insertion?Loss?(dB)(S/P?Grade) |
?4.0/3.8 |
?7.3/7.0 |
?10.5/10.2 |
13.7/13.5 |
16.9/16.5 |
21.0/20.5 |
|
Loss?Uniformity?(dB) |
0.4 |
0.6 |
0.8 |
1.2 |
1.5 |
2.5 |
|
Return?Loss?(dB)?(S/P?Grade) |
50/55 |
50/55 |
50/55 |
50/55 |
50/55 |
50/55 |
|
Polarization?Dependent?Loss(dB) |
0.2 |
0.2 |
0.3 |
0.3 |
0.3 |
0.4 |
|
Directivity?(dB) |
55 |
55 |
55 |
55 |
55 |
55 |
|
Wavelength?Dependent?Loss(dB) |
0.3 |
0.3 |
0.3 |
0.5 |
0.5 |
0.5 |
|
Temperature?Stability(-40～85?℃)(dB) |
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
|
Operating?Temperature?(℃) |
-40～85 |
|||||
|
Storage?Temperature?(℃) |
-40～85 |
|||||
