6 routes LNB FTA digital satellite receiver, digital TV headend

Brand Name	Jiehao		Place of Origin	China
Model Number	JXDH-6002-6

Detailed Product Description

 Support 6 routes LNB independent input or loop input, 1 route ASI-TS stream output, one backup of ASI-TS stream output
6 routes LNB FTA digital satellite receiver

Outline

JXDH-6002-6 QPSK Demodulator is used for receiving and transferring DVB-S channels to TS stream signal directly, then convert via FPGA outputting ASI to devices such as Multiplexer or Modulator. No need to do process of decompression, encoding etc. It is widely used in satellite digital TV, data broadcasting, Internet, etc.



Features

1) Support 6 routes LNB independent input or loop input, 1 route ASI-TS stream output, one backup of ASI-TS stream output;

2) LNB input frequency range: 950~2150 MHz;

3) Interface complies with ASI standard;

4) DVB/MPEG-2 both compatible;

5) SCPC/MCPC compatible, can receive all domestic and foreign non-encrypted digital programs;

6) Polarization mode: Horizontal/vertical for optional;

7) F head for optional;

8) C/Ku band compatible;

9) Adopt ultra-low threshold integrated tuner, high reliability, good performance, power off memory;

10) Stable and reliable performance, strong anti-interference capability.
