8 routes ASI input MPEG2 standard digital TS multiplexer, CATV digital headend

Brand Name	Jiehao		Place of Origin	China
Model Number	JXDH-6102S

Detailed Product Description

digital TS multiplexer
input MPTS analysis, and PID filter /PID redefine function
MPEG2 standard
package format :188/204

8 routes ASI input MPEG2 standard digital TS multiplexer

Outline

JXDH-6102S single multiplexer, is a digital broadcasting TV system TS stream re-multiplexer. Based on PID package interchange technology, it can combine several single-programs or multiple-programs, which are compressed, coded, and multiplexed according to customer request by head-end, into single transport stream. And it can insert EPG(Electronic Program Guide),CA(Conditional Access)and data broadcast signal into the output TS stream. It adopted the solution of minimum volume and lowest price, and it meets MPEG-2 standard, can be used in TV station, digital video inspection, and so on.

Features

1) Support up to 8 routes ASI inputs, can be cascading

2) Output code rate continuously adjustable, max output real data rate to 100Mbps

3) Support up to 155Mbps real data rate for each route input, and support package burst mode

4) Input TS stream package length (188/204) adapting

5) 3 routes ASI output interfaces

6) With input MPTS analysis function, display the input programs and output valid stream

7) High definition PCR adjustment, average PCR tremble keep in 20-60ns

8) PID filter/PID redefine function, the customer can add/delete programs and PID, also modify PID

9) LCD panel, can inspect the system status in real time, and set the parameters of multiplexer remotely

10) With Ethernet interface, can control the multiplexer through PC remotely

11) With parameters save function, the parameters will be call out automatically when turn on the multiplexer.

12) Failure insulation function, one abnormal input TS stream will not impact other TS streams

13) Very low time delay, the time between input and output will keep in 1 ms

14) With bandwidth protection function

15) Code rate adapting. When VBR change, it can keep toal output code rate constant

16) Support CA system, EPG, EMM and ECM

17) With PSI creating function. The customer can edit SDT and NIT, and extend their SI service via Ethernet
