HD Set Top Box(STB)

Brand Name	Jiehao		Place of Origin	China
Model Number	JXHD

Detailed Product Description

Encoding standards like VC-1, MPEG2, MPEG4, H.264, AVS, etc, which is widely used for IPTV group broadcasting, VOD and PPPoE

IPTV STB compiles with various encoding standards like VC-1, MPEG2, MPEG4, H.264, AVS, etc, which is widely used for IPTV group broadcasting, VOD and PPPoE service for TV operators, local district, hotels and bandwidth internet. Embedded with USB 2.0 port, which can be used as PVR function and other customized function.

Feature:


Comply with VC-1, MPEG2, MPEG4, H.264, AVS encoding standard;
Support RTSP, RTP, UDP, TCP and other internet protocol;
Support JPEG, BMP, PNG, and GIF graphic mode;
10/100M Ethernet port;
Embedded browser, support HTML Web browsing;
PPPoE, DHCP and statistic IP input mode;
Support Video on Demand service;
Support Unicode character display (Chinese and English)
USB 2.0 port supports customized requirements.


Technology Parameter:


Video Decoding

Complies with AVS MP@L3,WMV9/VC-1 MP@ML and AP@L1/H.264/MPEG-2 MP@ML;
support 4/3,16/9; Support PAL/NTSC; 720*576(PAL)or 720*480(NTSC) output.
Audio Decoding

Supports WMA-9/9 Pro, MPEG-1 Layer1/2, MPEG-2 layer 2, MPEG-2 AAC,
MPEG-4 AAC, MPEG-4 AAC+SBR and other leading audio standards; Mono/Stereo sound.
Chipset and Memory Chipset model: NXP 225; Flash memory: 16Mbytes; DDR SDRAM: 128Mbytes.
AV Output
Video Output Resistance: 75Ω; Video Output Level: 700±30mV;
Audio mode: Mono, Stereo, SPDIF; Audio Output Frequency: 20Hz~20KHz;
Audio Output Resistance: Low; Video Output Level: 0±6dBu.
Front Panel
One smart card slot; LED display;
RF receiver; One power display light, one status display light
Rear Panel
Video: one RCA output, one S-VIDEO, one YUV output (optional); Audio: Stereo (two RAC);
One RJ45 10/100M Ethernet port; One USB2.0;
One SPDIF; One RS 232 port.
Application Software
Embedded Ipanel middleware; HTML4.0,JavaScript 1.5;
Support GIF,JPEG,BMP,PNG graphic mode; Customized UGI language.
IPTV STB compiles with various encoding standards like VC-1, MPEG2, MPEG4, H.264, AVS, etc, which is widely used for IPTV group broadcasting, VOD and PPPoE service for TV operators, local district, hotels and bandwidth internet. Embedded with USB 2.0 port, which can be used as PVR function and other customized function.
