MPEG-2 to H.264 Encoder and Transcoder

Brand Name	Jiehao		Place of Origin	China
Model Number	JXDH-6203

Detailed Product Description

MPEG-2 to H.264 Encoder and Transcoder, Excellent error recovery capability


MPEG-2 to H.264 Encoder and Transcoder

Outline:

JXDH-6203 Transcoder is the latest successive version of H.264/AVC Encoder plus the MPEG-2 to H.264/AVC Transcoder. JXDH-6203 Transcoder accepts HD-SDI embedded audio, HDMI or CVBS input for encoding, the final output is available in ASI format or IP out. With extraordinary picture quality and significant bandwidth liberation, Transcoder is the best choice for the digital head-end system that has high bandwidth requirements. Transcoder SD/HD Encoder can provide excellent video performance even in CBR and VBR operating mode with low bit rate.


Features:

Video coding complied with H.264/AVC High Profile Level 4.0;
Video bit rate adjustment range: 1.1-10Mbit/s (SD); 3-20Mbit/s (HD);
TS to TS transcoding MPEG-2 HD to H.264 HD/SD, or MPEG-2 SD to H.264 SD CBR and VBR bit rate modes available;
Graphic resolution supports 1920*1080-24p, 1920*1080-60i, 1920*1080-50i, 1280*720-60p, 1280*720-50p, 720*576-50i, 720*480-60i;
Audio coding adapts MPEG-1 Audio Layer 2 and Dolby AC-3.;
Audio bit rate supports: 64Kbit/s, 96Kbit/s, 112Kbit/s, 128Kbit/s, 160Kbit/s, 192Kbit/s, 224Kbit/s, 256Kbit/s, 320Kbit/s, and 384Kbit/s;
Excellent error recovery capability;
Encoding resolution auto recognized.
1U single rack unit chassis, LCD panel operation.
TS IP output and DVB ASI output synchronically.
