FTA satellite receiver 6 in 1 with CH multiplexing function

Brand Name	Jiehao		Place of Origin	China
Model Number	JXDH-6002

Detailed Product Description

 FTA satellite receiver for receiving & transferring DVB-S channel to TS stream signal,convert via FPGA outputting ASI to device

FTA satellite receiver:

JXDH-6002-6 QPSK TS Demodulator used for receiving and transferring DVB-S channels to TS stream signal directly, then convert via FPGA outputting ASI to devices such as Multiplexer or Modulator. No need to do process of decompression, encoding etc. It is widely used in satellite digital TV, data broadcasting, Internet, etc.


1.2 Features

l Support 6 routes LNB independent input or loop input, 1 route ASI-TS stream output, one backup of ASI-TS stream output;

l LNB input frequency range: 950~2150 MHz;

l Interface comply with ASI standard;

l DVB/MPEG-2 both compatible;

l SCPC/MCPC compatible, can receive all domestic and foreign non-encrypted digital programs;

l Polarization mode: Horizontal/vertical for optional;

l F head for optional;

l C/Ku band compatible;

l Adopt ultra-low threshold integrated tuner, high reliability, good performance, power off memory;

l Stable and reliable performance, strong anti-interference capability.


Application:

l Digital satellite television broadcasting;

l MMDS digital TV front-end;

l Digital cable television network



1.3 Performance Indicator

Model
JXDH-6002-6 QPSK TS Demodulator

Input Frequency
9502150MHz

Signal level
-79-11dBm

IF band width
2736MHz

Modulate mode
QPSKDVB-S

Impedance
75W



ASI OutputAsynchronous serial interface

Socket
BNC

Impedance
75Ω

Packet format
188/204byteoptional

Channel date rate
270Mbps

Standard
comply with DVB standard
