4 in 1 QAM Modulator with DVB-S RF Input

Brand Name	Jiehao		Place of Origin	China
Model Number	JXDH-6303

Detailed Product Description

4 in 1 QAM Modulator with DVB-S RF Input
1. 4 ASI inputs
2. Support DVB-S/S2/T RF Input(optional)

4 in 1 QAM Modulator with DVB-S RF Input

Outline

JXDH-6303 4 in1 QAM Modulator is a high performance device researched by Chengdu Jiexun Electronics Co., Ltd., integrate 4 routes QAM modulating carrier outputs, support 4 ASI inputs or DVB-S/DVB-S2/DVB-T standard RF input(selectable built-in tuner), after 4 separate encoding and modulating, then RF out directly in high performance.

Support local and remote control to adjust the device parameter, equal to 4 individual QAM modulators, so cost and space saved.

Features
Fully support EN300 429/ITU-T J.83A
4 neighbor frequency QAM modulating carrier Output
4 ASI inputs, support 188/204 byte TS package
Support DVB-S/DVB-S2/DVB-T RF Input (optional)
Support PCR accurately correct
Constellation: 16QAM,32QAM,64QAM,128QAM,256QAM
Symbol Rate: 5.0Mbps~7.0Mbps
Support NIT insert, update
RF output frequency: 48MHz~860MHz,
RF output Level: -16dBm~0dBm,stepping at 0.5dB step
LCD display panel to operate
Support network management (NMS)
