CATV equipment: DVB TS Multiplexer 8 input 4 output

Brand Name	Jiehao		Place of Origin	China
Model Number	JXDH-6102

Detailed Product Description

TS Multiplexer,Complying ISO13818 standard.
Support MPEG-2 transport stream re-multiplexing.
Multiplexing SPTS and MPTS code


JXDH-6102 TS multiplexer is a digital broadcasting TV system TS stream re-multiplexer.JXDH-6102 multiplexer combines several single-programs or multiple-programs, which are compressed, coded, and multiplexed according to customer request by head-end, into single transport stream. Besides, it is also able to interpolate EPG (Electronic Program Guide), CA (Conditional Access) and digital broadcasting etc.Maximally, it can synchronal multiplex 8 route input code streams, and support ASI interface. The code rate of input code stream is maximally up to 270Mbps, while code rate of four separate outputs code stream is maximally up to 108Mbps. Through auxiliary data input channel, Its dimension is standard 1U case. By watching the LCD display on the front panel, user can finish the setting of auto-running of this device

Features
Complying ISO13818 standard.
Support MPEG-2 transport stream re-multiplexing.
Multiplexing SPTS and MPTS code stream.
SDT table reflection
Able to connect independent scrambler for scrambling to specified program or service.
Generating SPI/SI information
Support PCR adjusting and PID re-reflection
Able to extract PSI/SI information from any route of SPTS/MTPS inputs
Able to interpolate data, and re-multiplex and transport any kind of data
Support statistic multiplex
Support the cascading connection of several equipments.
Central net administration, remote updating and maintenance
LCD display, flexible and user-friendly in operation
High reliability design, stable in running
Alarm display
Support network upgrade
Two groups ( four routes) separate output channel,support two separate outputs.


Specifications:
Input Interface

ASI :8 Routes Standard ASI Interfaces;Maximum 270Mbps per route
Re-multiplexing

Re-multiplexing MPEG-2 stream;PID re-reflection;PCR reset;Automatically generating PSI/SI table
Output Interface

ASI:4 routes(2 groups separate output)
PID

Output PID range:000-1FFF
Random PID transparent transport :Random PID transparent transport possible
Max PID number for each input:64
Data input

Format: Auto identification, 188/204byte,encoding
Ethernet port:10Base-T Ethernet port
Dimension:44mmx482mmx410mm
Temperature: 0-45(Operating);-20-80(Storage)
Power:220VAC±10%,50HZ,25W.
