DVB-C QAM Set Top Box(STB)

Brand Name	Jiehao		Place of Origin	China
Model Number	Jiehao

Detailed Product Description

The device meets the DVB-C standard and supports English and Chinese interfacing as well as multi condition receiving system.


Description:

The device meets the DVB C standard and supports English and Chinese interfacing as well as multi condition receiving system, PAL/NTSC auto switching, EPG pre-viewing. It supports text messaging and program editing, mobile and deleting etc. It contains the Locking functions, Power-off memory, LED display, one key return and supports single voice channel, dual voice channel and stereo channels. It contains a range of games and supports Loader technology, on-line upgrade, on display of advertises and advertise menu.



Specifications:
Item
Specs

Input frequency
51858MHz

input Level
45dBμv85dBμv

Input reflecting loss
≥8dB

Input Resistance
75Ω

modulation
16QAM32QAM64QAM128QAM256QAM

symbol rate
3.66.952Mbauds

bandwidth
8MHz

Decoding mode
MPEG-2 MP@ML

Resolution
720×576(PAL)720×480(NTSC)

Picture output
1VP-P 75Ω

Sound output
20Hz20KHz 600Ω imbalance

Voltage
100250V 50/60Hz

Power
≤12W

Work Temperature
040

Storage Temperature
-2060

Relative Humidity
1090%
