PVC UH True Ball Valve With Electric Actuator Two Side Flange Adaptor (24 V DC) Emergency Manual Control
- Shanghai/Ningbo
- T/T L/C D/P D/A
You May Like
-
PVC UH True Ball Valve For Acid, With Electric Actuator One Side Female Threaded (110-260 V AC) Emergency Manual Control
-
PVC UH True Ball Valve With Electric Actuator One Side Female ThreadedC Emergency Manual Control
-
UPVC Union type diaphragm valves DIN PN16 (ANSI SCH 80)
-
UPVC Drainage Non-Return Valve DIN
-
UPVC/ CPVC/ PP Flanged Ball Check Valves ANSI
-
UPVC CPVC ABS Compact ball valves ANSI JIS DIN BS
Product Details
| Material | Other, UPVC | Technics | Casting | |
| Type | Other, Ball Valve | Place of Origin | Kocaeli, Turkey | |
| Model Number | PN16 | Brand Name | TU | |
| Connection | Female | Shape | Equal |
Product Description
Options:
It can have a battery powered on off safety command.
Proportional Control Unit, potentiometer,local control unit,position transmitter options are availabke.
Actuator flange connection measures ISO 5211
24V DC/24V AC
Flange connection mensures:ISO 7005/ EN 1092/ DIN 2501 PN10/ BS4504
Availability exist for new options which can be added according to the needs.
Dia | BSP (Inch) | PN | DN (mm) | kv-value l/min. | Z (mm) | L1 (mm) | L (mm) | H (mm) | H1 (mm) | ISO5211 Interface |
20 | 1/2″ | 16 | 15 | 185 | 60 | 48 | 123 | 209 | 27 | F 03 |
25 | 3/4″ | 16 | 20 | 350 | 58 | 45 | 140 | 215 | 31 | F 03 |
32 | 1″ | 16 | 25 | 700 | 68 | 49 | 158 | 225 | 33 | F 05 |
40 | 1 1/4″ | 16 | 32 | 1000 | 82 | 54 | 186 | 238 | 41 | F 05 |
50 | 1 1/2″ | 16 | 40 | 1600 | 94 | 65 | 231 | 253 | 46 | F 05 |
63 | 2″ | 16 | 50 | 3100 | 98 | 74 | 253 | 288 | 58 | F 07 |
75 | 2 1/2'' | 16 | 65 | 5000 | 119 | 87 | 291 | 305 | 65 | F 07 |
90 | 3″ | 16 | 80 | 7000 | 156 | 98 | 353 | 352 | 89 | F 07 |
110 | 4″ | 16 | 100 | 11000 | 185 | 150 | 431 | 385 | 105 | F 07 |
Dia | BSP(Inch) | PN | Kg/Pcs | Box/Pcs | EPDM & PTFE O-RINGCode |
20 | 1/2″ | 16 | 1.660 | 1 | 306 00 020 2 |
25 | 3/4″ | 16 | 1.775 | 1 | 306 00 025 2 |
32 | 1″ | 16 | 1.965 | 1 | 306 00 032 2 |
40 | 1 1/4″ | 16 | 2.385 | 1 | 306 00 040 2 |
50 | 1 1/2″ | 16 | 2.745 | 1 | 306 00 050 2 |
63 | 2″ | 16 | 3.595 | 1 | 306 00 063 2 |
75 | 2 1/2'' | 16 | 5.490 | 1 | 306 00 075 2 |
90 | 3″ | 16 | 7.970 | 1 | 306 00 090 2 |
110 | 4″ | 16 | 10.535 | 1 | 306 00 110 2 |
