UPVC CPVC PVDF PP Diaphragm Flanged Valves ANSI DIN JIS/regulating Valve
Negotiable
/ Carton
5 Cartons(Min. Order)
- Shanghai/Ningbo
- T/T
You May Like
-
ABS Flange Diaphragm Valves DIN (Civil)/ABS Flange Diaphragm Valves
-
Industrial CPVC Flanged Diaphragm Valves JIS/JIS Diaphragm Valve
-
Union Type Diaphragm Valves DIN PN16 (ANSI SCH 80)/UPVC Union Type Diaphragm Valves
-
UPVC/ CPVC Flanged Single Union Foot Valves ANSI/dark Gray Foot Valve
-
UPVC Spring Foot Valves JIS ANSI DIN/UPVC Spring Foot Valves
-
Industrial CPVC Bottom Valves JIS/CPVC Bottom Valves
Product Details
| Material | Other, Plastic, PVC CPVC PVDF PP | Type | Other, Valves | |
| Place of Origin | Zhejiang, China | Model Number | DIN,ANSI,JIS | |
| Brand Name | TU |
Product Description
Specifications
Name: UPVC CPVC PVDF PP Diaphragm flanged valves ANSI DIN JISMaterial: PVC CPVC PVDF PP
Standard: ANSI DIN JIS
| Size | Standard | Material | Gasket | O-ring | Diaphragm | End type | Bolt |
| 1/2"~8" | ANSI,JIS,DIN | PVC | PTFE | NBR | EPDM,FPM,PTFE | Flanged | SUS 304 / 316 |
| 1/2"~8" | ANSI,JIS,DIN | CPVC | PTFE | NBR | EPDM,FPM,PTFE | Flanged | SUS 304 / 316 |
| 1/2"~8" | ANSI,JIS,DIN | PVDF | PTFE | NBR | EPDM,FPM,PTFE | Flanged | SUS 304 / 316 |
| 1/2"~8" | ANSI,JIS,DIN | PP | PTFE | NBR | EPDM,FPM,PTFE | Flanged | SUS 304 / 316 |
| NO. | PART | MATERIAL | Q'TY |
| 1 | BODY | UPVC,CPVC,PP,PVDF | 1 |
| 2 | BONNET | UPVC,CPVC,PP,PVDF,PP+GF | 1 |
| 3 | COMPRESSOR | FC,SUS,PPG,PVDF | 1 |
| 4 | HANDWHEEL | PP | 1 |
| 5 | SLEEVE | C3602,SUS | 1 |
| 6 | STEM | C3602,SUS | 1 |
| 7 | DIAPHRAGM | EPDM,FPM,PTFE | 1 |
| 8 | CAP | UPVC,CPVC,PVDF | 1 |
| 9 | COMPRESSOR PIN | SUS 304 | 1 |
| 10 | INSERTED METAL | C3604,SUS304 | 1 |
| 11 | GREASE NIPPLE | C3604,(65-200) | 1 |
| 12 | BOLTS&WASHER | 200mm---16set | SUS 304/316 |
| 13 | INSERTED NUT | 150mm---12set | |
| 65-125mm---8set | |||
| 14 | NUTS&WASHER | 25-50mm---6set | |
| 15 | THRUST BEARING | STANDARD(100-200) | 1 |
| 16 | STOPPER | SUS 304 | 1 |
| 17 | SET NUT | SUS 304 | 1 |
| 18 | GAUGE COVER | AS | 1 |
| 19 | SHEET GASKET | EPDM | 1 |
| 20 | SHEET RING | SUS 304 | 1 |
| 21 | SPRING WASHER | SUP | 1 |
| 22 | O-RING | NBR | 1 |
| 23 | LOGO PLATE | UPVC | 1 |
Pressure rating: 1/2"~3" 150 PSI, 4"~6" 72 PSI, 8" 43 PSI (Working pressure is
varified by rawmaterial of diaphragm and temperature.)
Smooth operation with clear indication of opening / closing through the gauge cover
Low maintenance cost with replaceable diaphragm and long service life
Adjustable stopper can avoid over tighteness.
Caution! The valve is completely closed when handwheel can't turn more with normal torque,
but it will cause the unrecoverable divulsion of diaphragm if the handwheel is continuously forced to turn in such above condition!
