CE big Backhoe fitted with tractor PTO with three point linkage ,with self Gearbox

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	HT-LW
Model Number	TZ04,06,08,10		Condition	New

This series backhoe can matched with DIFFERENT BRABD tractors and also DIFFERENT HP tractor

SPECIFICATION OF BACKHOE

Model	LW-6	LW-7	LW-8
Maximum Digging Depth	6'0"	7'0"	8'0"
A. Digging Depth (two foot flat bottom)	5'6"	6'6"	7'6"
B. Swing Arc	180 °	180 °	180 °
C. Loading Height (bucket at 60 ° )	5'0"	5'0"	5'10"
D. Reach from Center Line of Swing Pivot	8'6"	8'6"	9'6"
E. Transport Height (maximum)	4'11"	4'11"	5'9"
F. Bucket Rotation	180 °	180 °	180 °
G. Loading Reach (bucket at 60 ° )	3'2"	3'2"	3'7"
H. Transport Overhang	3'5"	3'5"	3'6"
I. Undercut	2'4"	2'4"	2'6"
J. Stabilizer Spread, down position	6'6"	6'6"	7'5"
K. Stabilizer Spread, up position	3'11"	3'11"	5'1"
Bucket Cylinder Digging Force	2450 lbs	2450 lbs	2840 lbs
Dipper stick Cylinder Digging Force	1250 lbs	1250 lbs	2005 lbs
Shipping Weight (less bucket)	586 lbs	654 lbs	875 lbs
Hydraulic Volume Requirements	4 to 5 GPM	4 to 5 GPM	5 to 6 GPM
Hydraulic Pressure Requirements	2250 psi	2250 psi	2250 psi
Recommended Tractor HP Requirements	15 - 30 HP	18 - 35 HP	25 - 45 HP
Specifications May Very Depending on Tractor Model and Subject to Change Without Notification.
Tractor Must Be Equipped with ROPS and Seat belt That will Provide Better Safety.
