Stand Alone Scrambler frequency
- CHEGNDU
- Credit Card
You May Like
Product Details
Place of Origin | Sichuan, China | Brand Name | shida | |
Model Number | SDC-3000S |
Product Description
Specifications
simul-crypt scramble the input streamworks with the CA system
used in the digital TV scrambling field.
Outline: The Stand Alone Scrambler can simul-crypt scramble the input stream, and the embedded control word generator
can transmit the constant or variable control word to scrambler the input transmitting stream. The internal simul-crypt
synchronous controller can transmit the control word and the access conditions to exchange the information with the
ECMG. When the scrambler works with the CA system, it can easily help the decoder to correctly decrypt the control
word, and decode the scrambling stream by properly controlling the CP. Its high compatibility and integrate design make
this device widely being used in the digital TV scrambling field.
Features
1 Adopts the general scrambling system description ETR289
2 It can DVB scramble the specific program or the basic transmitting stream
3 Complies with the DVB common scrambling algorithm, supports the simulcrypt mode, be compatible with a
variety of CV systems.
4 Analysis the overall MPEG stream
5 Re-treating the PSI/SI
6 Protecting the input and output ASI stream channel
7 Supports four different CAS system simultaneously
8 Supports huge buffer memory, and resists the unexpected code stream
9 Supports the bit-rate self-adoption, the re-adjustment and the re-mark of PCR
10 Real-time effective bit-rate monitoring
11 The database format: 188/244 bytes
12 Monitoring the work state by network system
13 Supports the CAS remote connection scrambling
Specification
Input interface | Two DVB/ ASl (one for reserve) | |
Output interface | Two DVB/ ASl | |
Output bit-rate | 1~54mpbs | |
Management | Ethernet port 10/100M | |
General | Dimension | 482mm×410mm×44mm |
Weight | 3.5kg | |
Work temperature | 0~45°C(working ),-20~80°C(storage) | |
Power supply | AC 110V±10%,50/60Hz or AC 220V±10%,50/60Hz | |
Power consumption | 11W |
