Home > Products > DVB-C set top box > mpeg2 SD digital cable receiver
mpeg2 SD digital cable receiver
- Shengzheng
- T/T Credit Card
You May Like
Product Details
| Brand Name | shida | Model Number | SDC-3000C5 |
Product Description
Specifications
Support 5 ways advertisemenMINI metal casing
free software support for lifetime
Characteristics
l The device meets the DVB standard and supports English and Chinese interfacing as well as multi-condition receiving system,
2 PAL/NTSC auto switching, EPG pre-viewing.
3 Power- off memory function.
4 Contains the Locking functions, LED display.
5 Single voice channel, dual voice channel and stereo channels.
6 Contains a range of games and supports Loader technology.
7 On-line upgrade, on display of advertises and advertise menu.
8 Support broadcasting.
9 Support receiving Mosaic effect program.
10 Support 5 ways advertisement ( if choose to use ADS system)
11 Support 500 channels memory
12 Subtitle available
l3 Double AGC control
l4 Built in OTP
Technical Specification | |
| |
Item | Specs |
Input frequency | 87-862MHz |
input Level | 40dB-90dB |
Input reflecting loss | >8dB |
Input Resistance | 75Ω |
modulation | 16QAM32QAM64QAM128QAM256QAM |
symbol rate | 3.6---6.952Mbauds |
bandwidth | 8MHz |
Decoding mode | MPEG-I MPEG-2 mpeg4 MP@ML |
Resolution | 720×576(PAL)720×480(NTSC) |
Picture output | 1VP-P 75Ω |
C/N | <26db 64qam <33dB 256qam |
CPU | HM1521 |
Flash | 2 MByte |
RAM | 16MByte |
Tuner | NXP18250 |
CAS | DEXIN 5.1
|
Frequency capture range | ±150KHz 64QAM,6.875Mbaud |
Audio decoding | MPEG-1-Audio LayerⅠ/Ⅱ MPEG-2-Audio Mono / stereo |
Audio sampling rate | 32,44.1,48KHz |
PCR jitter adaptive capacity | >500ns,<-500ns |
Boot time | <30S |
The channel switching time | < 2.5S |
storable programs | 1000 |
Voltage | 100-250V 50/60Hz |
Power | <12W |
Casing | Metal |
Size | 22cm*14.3cm*3.8cm |
Work Temperature | 0-45 |
