Horizontal Electric Anchor Windlass
- T/T
You May Like
Product Description
Horizontal Electric Anchor Windlass
TECHNICAL SPECIFICATIONS
1, anchor chain diameter 19/22mm
2, the maximum anchor weight 500kg
3, the working load 1565/2100kg
4, supporting load 9180kg
5, anchoring depth of 82.5m
6, anchor chain length of 225m
7, the anchor speed 4/12m/min
8,Rated mooring pull 1000kg
9, the speed of mooring ≥ 10m/min
10, the diameter of wire rope (hemp rope circumference) 11 (125)
11, the mechanical transmission ratio of 96.1
12, the mechanical efficiency of 0.6
13, motor specifications
Model
Power 8.5/3.5kw
Speed 1500/500rpm
Voltage 380V
Motor working system 30/10min
Weight (without motor) 1055kg
Certificates: ABS,BV, CCS, GL, LR, ,NK, RMS, etc.
Chain Dia. (mm) | Working Load (kN) | Supporting Load (kN) | Working Speed (m/min) | Warping Load (kN) | Motor Power (kW) |
12.5 | 5.9 | 30 | ≥9 | 5 | 3/1.2 |
14/16/17.5 | 8.3/10.9/13.0 | 51/67/80 | ≥9 | 8 | 4.3/1.7 |
19/20.5/22 | 15.3/17.9/20.6 | 95/110/126 | ≥9 | 10 | 8.5/3.5 |
24/26 | 24.5/28.7 | 149/175 | ≥9 | 20 | 8.5/3.5 |
28/30 | 33.3/38.3 | 202/231 | ≥9 | 30 | 11/11/7.5 |
32/34/36 | 43.5/49.1/55.1 | 261/294/329 | ≥9 | 30 | 16/16/11 |
38/40/42 | 61.4/68.0/75.0 | 365/402/442 | ≥9 | 40 | 22/22/16 |
44/46/48 | 82.3/89.9/97.9 | 483/526/570 | ≥9 | 50 | 30/30/22 |
50/52/54 | 106.3/114.9/123.9 | 617/664/713 | ≥9 | 50 | 30/30/22 |
56/58/60 | 133.3/143.0/153 | 764/816/870 | ≥9 | 60 | 45/45/30 |
62/64 | 163.4/174.1 | 925/982 | ≥9 | 80 | 45/45/30 |
66/68 | 185.1/196.5 | 1040/1098 | ≥9 | 100 | 45/45/30 |
70/73 | 208.3/226.5 | 1160/1254 | ≥9 | 100 | 60/60/45 |
76/78 | 245.5/258.6 | 1350/1416 | ≥9 | 125 | 60/60/45 |
81/84 | 311.7/335.2 | 2171/2320 | ≥9 | 140 | 75/75/36 |
87/90 | 359.5/384.8 | 2473/2629 | ≥9 | 150 | 75/75/36 |
92/95 | 402.0/428.7 | 2735/2898 | ≥9 | 200 | 85/85/64 |
97/100 | 446.9/475.0 | 2995/3162 | ≥9 | 250 | 100/100/50 |
05/107 | 523.7/543.8 | 3612/3750 | ≥9 | 300 | 110/110/55 |
112/114 | 595.8/617.3 | 4109/4228 | ≥9 | 350 | 132/132/66 |
