Home > Products > Marine Deck Equipment > Marine Deck Machinery Equipment Anchor Capstan Winch/ Deck Capstan Winch
Marine Deck Machinery Equipment Anchor Capstan Winch/ Deck Capstan Winch
- shanghai
- T/T
You May Like
Product Details
| Place of Origin | Chongqing, China | Power Source | Other, Hydraulic or Electric | |
| Application | Boat | Capacity | 5KN-100KN |
Product Description
electric combined anchor mooring capstan vertical
.Saving a lot of weight and space
..The electric motor is frequency controlled or pole changeable for different speeds
. Certification by all major classification societies possible
. Brake holding force 80% possible, so there is no need to install a chainstopper
. Effective warping need
. Foundation adapted to frame distance of ship’s construction
. Highly efficient, reliable. Compact and low weight design.
. Various potions on dimensions possible.
. Low noise level, environmental friendly.
. The gear case is provided with oil
OPTIONS AND EXTRAS
. Speed control system for paying in the chain to prevent damage to the hull and anchor pocket
. Automatic speed control system for paying “out" the chain and anchor(automatic anchor drop system)
.Automatic mooring operation by means of self-tensioning
. Low speed option for clutch operation
. Hydraulic or pneumatic operated clutch
. Hydraulic or pneumatic operated brakes
. Alarm signal to the boards alarm system
. Higher levels of water tightness above IP56
. Finished with full paint system
. Radiographic controls
. Remote controls
. Footswitch operation
Datasheet
Chain dia(mm) | Working load(kn) | Working speed(m/min) | Warping load(kn) | Warping speed(m/min) | Wire dia(mm) | Motor power | |
| Electric(kw) | Hydraulic(kw) | ||||||
| 12.5 | 5.9 | ≥9 | 5 | ≥9 | 11 | 3.0/1.2 | 4 |
| 14 | 7.4 | ≥9 | 5 | ≥9 | 11 | 3.0/1.2 | 7.5 |
| 16 | 10.9 | ≥9 | 8 | ≥9 | 13 | 4.3/1.7 | 7.5 |
| 17.5 | 13 | ≥9 | 8 | ≥9 | 13 | 4.3/1.7 | 11 |
| 19 | 15.3 | ≥9 | 10 | ≥9 | 13 | 6.0/2.5 | 11 |
| 22 | 20.6 | ≥9 | 10 | ≥9 | 13 | 7.5/7.5/5.0 | 11 |
| 26 | 28.7 | ≥9 | 20 | ≥9 | 15 | 11/11/7.5 | 15 |
| 28 | 38.3 | ≥9 | 30 | ≥9 | 17.5 | 16/16/11 | 15 |
| 32 | 49.1 | ≥9 | 30 | ≥9 | 17.5 | 16/16/11 | 18.5 |
| 36 | 61.4 | ≥9 | 50 | ≥9 | 20.5 | 22/22/16 | 30 |
| 38 | 68 | ≥9 | 50 | ≥9 | 20.5 | 22/22/16 | 30 |
| 42 | 82.3 | ≥9 | 50 | ≥9 | 20.5 | 22/22/16 | 30 |
