Anchor Capstan for Boat/ Capstan Winch Marine
- shanghai
You May Like
Product Details
| Place of Origin | Chongqing, China | Brand Name | Perpetual | |
| Model Number | JM | Power Source | Electric | |
| Application | Boat |
Product Description
Specifications
Electric Capstan Winches1.Max Capacipty:65T;
2.Professional after-sales team;
3.CE,BV,ISO,SGS,GOST;
Brief introduction of Capstan winch
The capstan winch has electric type and hydraulic type, suitable for ship mooring, anchoring and warping hawser. The capstan is mainly made up of motor, reducer, capstan, brake and so on. The capstan is mainly used on boat; the pulling force is from 5KN to 1250KN.
1. Multiple usages, suitable for ship mooring, anchoring, warping hawser.
2. With electric type and hydraulic type.
3. Pulling force: 5KN -1250KN.
4. Small size and compact design.
5. Marine motor with electromagnetic brake.
6. Casting steel drum with Q345B steel.
1. We are the Group company which has 6 subsidiary companies with 200 millions USD yearly output value.
2. The few factory which can produce the construction winch, marine winch, mine winch with electric type, hydraulic type , diesel engine type.
3. With 3 senior engineers are the drafters of China Winch National Standard .We are the council member of Chinese winch association.
4. The leader of 6S management in winch and crane industry.
5. Our engineers are available to overseas anytime anywhere.
6.All kinds of winch can be customized according to your demands.
| Type | Warping load (KN) | Warping speed(m/min) | Wire Dia(mm) | Motor power (kw) | |
| Electric | Hydraulic | ||||
| D(Y)J5 | 5 | ≥18 | φ11 | 3/1.2 | 5.5 |
| D(Y)J10 | 10 | ≥18 | φ11 | 4.3/1.7 | 7.5 |
| D(Y)J20 | 20 | ≥18 | φ15 | 7.5/7.5/5 | 15 |
| D(Y)J30 | 30 | ≥18 | φ17.5 | 16/16/11 | 18.5 |
| D(Y)J40 | 40 | ≥18 | φ20.5 | 16/16/11 | 18.5 |
| D(Y)J50 | 50 | ≥18 | φ20.5 | 22/22/16 | 30 |
| D(Y)J70 | 70 | ≥15 | φ26 | 30/30/22 | 45 |
| D(Y)J100 | 100 | ≥15 | φ28 | 45/45/30 | 55 |
| D(Y)J120 | 120 | ≥15 | φ32.5 | 60/60/45 | 75 |
| D(Y)J150 | 150 | ≥15 | φ36.5 | 60/60/45 | 90 |
| D(Y)J200 | 200 | ≥15 | φ40 | 75/75/36 | 110 |
| D(Y)J250 | 250 | ≥12 | φ46 | 75/75/36 | 110 |
