Marine Anchor Capstan
- 5000 Set / Sets per Month
- shanghai
You May Like
-
Marine 20T Electric Hydraulic Knuckle Telescopic Crane
-
Deck Marine electric hydraulic crane
-
Electric Hydraulic Pipe Marine Handling Crane
-
Marine Deck Machinery Equipment electric hydraulic pedestal marine crane/ marine deck crane
-
marine capstan winch
-
Marine hydraulic winches/single drum/ double drum
Product Details
| Brand Name | Perpetual | Model Number | PPMC | |
| Part | Other, Capstan |
Product Description
Specifications
Vertical type,anchor handling and mooring purpose. Our advantages:reliable quality, low price, short delivery, good servicesMarine Anchor Capstan Technical Specification
1) Driven Mode: Electric or Hydraulic operated
2) Configuration: Vertical type, one gypsy,one warping head, compact structure.
3) Chain Diameter: From 12.5mm to 44mm, stud link chain Grade 2 or 3
4) Gypsy Rated Pull: 42.5d2/1000(KN) for grade 2 chain.
47.5d2/1000(KN) for grade 3 chain.
5) Anchor Lifting Speed: 9m/min
6) Warping Load: From 5KN to 50KN
7) Warping Speed: over 10m/min.
8) Brake & Clutch: Manual
9) Control Option: Local control
10) Certificate: ABS, GL, LR, BV, RMS, NK, CCS, etc.
Our Advantages
1) Much experience in manufacturing and exporting
2) High quality, but low price.
3) Special design to suites different clients' requirements.
4) Short delivery time if clients need urgently.
5) Strictly Final Acceptance Test(FAT).
