Marine Capstan / Electric Capstan/ Offshore Capstan/ Mooring Capastan

FOB Price

US$ 1 - 1 / Set

1 Set(Min. Order)

Port shanghai

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Chongqing, China	Brand Name	Perpetual
Model Number	CA-03	Power Source	Electric
Application	Boat	Capacity	3 to 15T

Product Description

Specifications

Electric capstan:
1.Vertically mounted.
2.Cast steel wraping head.
3. 3 to 15T pull@1st layer.
4.Max. speed 20m/min.

Electric capstan/ Marine capstan/ Boat casptan

Marine boat electric capstan

Perpetual electric Capstan is a vertical axled rotating machine used on sailing ships. It can apply force to ropes, cables, and hawsers. The principle is similar to that of the windlass, which owns a horizontal axle. Typically, it uses a gearbox which trades reduced speed, relative to the prime mover, for increased torque. Our company designs and produces capstan winches from simple light load to combined heavy load, which can lift pearl bags from the ocean floor to 30 ton line pull units for mooring large vessels. Modern capstan winches are powered electrically, hydraulically, pneumatically, or via an internal combustion engine.

Features of Capstan Winch:
1. This capstan can adopt electric or hydraulic drive.
2. Configurations are vertically mounted.
3. Warping head of the capstan uses cast steel.
4. Rated pull of the 1st layer can reach from 3MT to 15MT.
5. Max wire speed of this capstan winch is 20m/min.
6. Local control is available for customers.

Specifications of Capstan:

Model	Pull(MT)	Speed (M/MIN)	Warping Head Dia. mm	Power (Approx.)
TUFMDCA -3T/330	3	10	330	7.5
		15		11
TUFMDCA -5T/330	5	10	330	11
		15		15
TUFMDCA -5T/380		10	380	11
		15		15
TUFMDCA -8T/380	8	10	380	18.5
		15		30
TUFMDCA -8T/450		10	450	18.5
		15		30
TUFMDCA -10T/450	10	10	450	22
		15		30
TUFMDCA -10T/510		10	510	22
		15		30
