Home > Products > WELDING MACHINE > Inverter MMA Welding Machine ZX7-100
Inverter MMA Welding Machine ZX7-100
Negotiable
1 (Min. Order)
You May Like
Product Details
| Brand Name | Sihio | Model Number | ZX7-100 | |
| Rated Duty Cycle | 20% | Motor Type | AC Motor | |
| Dimensions | 400mm*300m*320m | Voltage | 1PH 200V |
Product Description
1.STICK WELDER
2.CE AND CCC APPROVE
3.SUPPORT OEM
Features:
- Inverter techique makes the welder runs welder runs in high utilization rate of power
- Low open circuit loss and has good welding quality.
- Suitable for MMA welding of low carbon steel and low alloy steel with all kinds of welding rod.
- High efficiency.
- High performance in DC MMA.
- Easy arc ignition, excellent formation of welding seam.
- Suitable for metal and pressure works, petrol-chemical plant etc.
| Model | ZX7-100 |
| Main Voltage (AC)(V) | 1PH 230 |
| Frequency (HZ) | 50Hz |
| Input Capacity (KVA) | 3.5KVA |
| No Load Voltage (V) | 70V |
| Welding Current ±10% (A) | 10-100 |
| Duty Cycle (%) | 20% |
| Power Factor (CosΦ) | 0.8 |
| Min Electrode (Φ)(MM) | 1.6mm |
| Ma Electrode (Φ)(MM) | 3.2 |
| Insulation Class (IP) | F |
| Protection Degree | IP21S |
| Dimension (MM) | 400mm*300mm*320mm |
| Weight (KG) | 7 Kilogram (KG) |
