SHANGHAI DONSUN Digital IGBT Industrial Grade WSM-400T/500T TIG GTAW Argon Tungsten-arc Welding
1 Sets
≥2 Sets
- shanghai
- T/T
- 7 days
You May Like
-
Shanghai Donsun LD-270/350/500 MIG/ARC/CUT 3in1 Multi-function Welding Machine
-
Shanghai Donsun Welding Group Spot Welding Machine Resistance Welding Machine DTM-20K/40K/80K /20K-S/40K-S MFDC Spot Welding Machine
-
Shanghai Donsun Welding Group New Foot-operated/Pneumatic Spot Welding Machine DN1-16N/25N/35N/ 16Q/25Q/25Q
-
Shanghai Donsun Pneumatic Desktop Spot Welding Machine DN-16Q/25Q 12 DTM-20K-T
-
Shanghai Donsun Spot Welding Resistance Welding Portable Spot Welding Machine DNY-5/16/25/50/80/100/150
-
SHANGHAI DONSUN Pedal-operated Spot Welding Machine DN-10/16/25/35
Product Details
| Type | TIG Welder | Style | Vertical | |
| Electric Current | DC | Cooling Way | Air Cooling | |
| Work Form | Other, IGBT | Frequency Range | High Frequency | |
| Transport Package | carton | Specification | customize | |
| Trademark | donsun | Origin | China |
Product Description
WSM-400T/500T
Industrial standard, multi-function, high duty cycle
· Advanced Inverter IGBT module technology.
Adaptable with generator, suitable for outdoor welding
·Pulse Width, Pulse Frequency, Up Slope, Down Slope and Post· gas Time
Function Adjustable.
Automatic Hot Start boosts the current during starting to make
striking an arc easier.2T/4T and Repeat Function Selectable on the
front panel
Remote Control Function Ready - Remotely controlling your current
level with a foot control.
·Auto-Protection against over-voltage, over· current and over-heated
Energy Saving - Compared with the traditional TIG machine more
efficient.
Digital control system
Over voltage / Over current /Over heat protection
Intelligent air cooling
ARC/TIG dual function
Model | WSM-400T | WSM-500T |
Rated input voltage (v) | 3P 380V±15% | 3P 380V±15% |
Rated input current (A) | 20.5 | 39 |
Open circuit voltage (V) | 69 | 70 |
Duty cycle (%) | 60@40℃ | 60@40℃ |
Constant current range (A) | 8-400 | 10-500 |
Peak current range (A) | 8-400 | 10-500 |
Welding current (A) | TIG:8-400 MMA:20-320 | TIG:10-500 MMA:20-400 |
Base value current range (A) | 8-400 | 10-500 |
Pulse frequency (HZ) | 0.1-99.9 | |
Pre-gas time (S) | 0-5 | 0-5 |
Post-gas time(S) | 1-60 | 1-60 |
Rise time (S) | 0-10 | 0-10 |
Down time (S) | 0-10 | 0-10 |
Efficiency (%) | 85 | 85 |
Power factor | 0.95 | 0.95 |
Protection class | IP21 | IP21 |
Insulation class | FF | F |
