Home > Products > Common Rail Equipment > CRS-1001 common rail system tester
CRS-1001 common rail system tester
Negotiable
/ Set
1 Set(Min. Order)
- Beijing
- Credit Card
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | Injectronix | |
| Model Number | CRS-1001 |
Product Description
Specifications
TheCRS-1001 tester can be used on a test bench, it can test CR systems with Bosch CP1/CP2/CP3, Delphi CRSP & Denso HP2/HP3 pumpThe repair tester CRS-1001 can be used on a test bench, it can test the CR systems with Bosch CP1/CP2/CP3 , Delphi CRSP pumps.
CRS-1001 simulates an engine ECU, to drive a solenoid on CR pump and solenoids of 6 CR injectors. A standard high pressure pump test bench with a CR system tester CRS-1001 will fulfill most tasks for repairing a CR system and the components, such as injection quantities, injector fuel return, nozzle injection spray atomization, pump condition and fuel rail pressure control.
Design Features
- Combine two independent modules for pump and injector control
- Pump driving signal - Adjustable duty cycle,while monitoring fuel rail pressure
- Injector driving signal - Adjustable frequency and pulse width
- Modulated driving signal to ensure the safety of the solenoids of the injectors
- Software based over-pressure protection
- Short circuit protection for solenoid driving signals
- Rich accessories, ready to test Bosch, Denso and Delphi injectors and pumps
NEW UPGRADE:
- The injection cycle counter with interface to a regular pump test bench has been added to the CRS-1001 tester.
