CRB-100 Banco de Prueba de Inyector Common Rail
Negotiable
/ Set
1 Set(Min.Order)
- 30 Set / Sets per Month
- Credit Card
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | Injectronix | |
| Model Number | CRB-100 | Power | Electronic | |
| Usage | Auto Testing Machine |
Product Description
Specifications
para realizar accionamiento hidraulico de banco de prueba para comprobar inyector common rail tanto electromagnetico como piezo
El CRB-100 se sirve para comprobar un inyector common rail con la tecnología electromagnética o piezoeléctrica. El banco de prueba tiene un integrado limpiador ultrasónico para limpiar los componentes sofisticados de inyector.
Función:
Medición de transporte y retorno de aceite de inyector common rail
Comprobación de patrón de pulverización de boquilla de inyector
Limipia los componentes sofisticados de inyector
Especificación
Especificación
Se usa un actuador neumático para agrandar para generar fuente de comustible de alta presión para alimentar inyector
Se necesita aire comprimido en el taller, 6-8bar, flujo de aire150L/min
Rango de presión de combustible 0-1200bar
Tipo de combustible: gasóleo
Estabilidad de presión de combustible +/-50bar
Se puede producir señales como lo hace motor ECU para accionar actuador tanto electromagnético como piezoeléctrico de un inyector common rail
Se puede ajustar frecuencia de inyección representada por la velocidad del motor, 0-4000rpm
Se puede ajustar anchura de pulsación de inyección, 0-6ms
Medición de transporte de combustible
Regularización de contador de inyección: 0-9999 inyecciones
Medición de transporte de combustible utilizando un cilindro de vidrio para seguir tanto inyección de combustible como fugas del inyector
Filtración de combustible:5µm
Integrado limpiador ultrasónico
Alimentación: 120W
dimensión de la cuenca: 300×240×150(mm)
Alimentación principal de CA, monofase, 500W, 220V/50Hz, o 115V/60Hz, o según especificación del cliente
