Home > Products > Common Rail Equipment > CRS-2000 Common Rail System Tester
CRS-2000 Common Rail System Tester
Negotiable
/ Set
1 Set(Min. Order)
- beijing
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | injectronix | |
| Model Number | CRS-2000 |
Product Description
Specifications
CRS-2000 Common Rail System Tester For Denso-U2.Test common rail system, consists of a Denso HP0 pump, a fuel rail and six inj
CR System Repair Tester CRS-2000 targets Denso CR systems with an HP0 or ECD-U2 pump. CRS-2000 simulates the Denso engine ECU, to drive two solenoids on an ECD-U2 pump and solenoids of 6 CR injectors.
A standard high pressure pump test bench with a CR system tester CRS-2000 will achieve most tasks for repairing a Denso ECD-U2 system and the components, such as injection quantities, injector fuel return, nozzle injection spray atomization, pump condition and fuel rail pressure control.
CRS-2000 application
Design Features
The CRS-2000 meets the synchronization requirement to drive an ECD-U2 pump and 6 injectors
Pump operation
Close-loop control of rail pressure to reach the required rail pressure
Manually adjust pump load
Injection operation
Injection frequency
Synchronous fuel injection with the ECD-U2 pump
Manually adjust fuel injection frequency
Adjustable pulse width
Short circuit protection for the output circuitry of the solenoid driving signal
Rich accessories, ready to test a DENSO ECD-U2 system
