HUATE BRAND: The First Nonvolatile 5.5T Cryogenic Superconducting Magnetic Separator in the World

Specifications

The First Nonvolatile 5.5T

Cryogenic Superconducting Magnetic Separator in The World

Patents No:

ZL201220044035.1     ZL201210065971.5     ZL201220063987.2
ZL201220093694.4     ZL201220093063.2     ZL201220093065.1

The application scope:

With the high intensity background filed, we can separate the weakly magnetic particles from ores. It can be used to separate the nonmetallic minerals such as the Kaolin and to treat sewage etc.

Working principle of the 5.5T Cryogenic Superconducting Magnetic Separator
The magnetic separator uses the characteristics that the superconducting coil resistance is zero in the low temperature (4.2 K), the superconducting coil with heavy current is immersed in liquid helium in order to make the background intensity reach 5.5T. Then the surfaces of magnetic stainless steel matrix in the separation canisters produce the extremely high gradient magnetic field. The separation system includes two separation canisters and three invalid separation canisters. The invalid canisters are to keep the balance with effective separation canisters then make the separation unit is moved with a little outside force.

The equipment site

The technical characteristics of 5.5T cryogenic superconducting magnetic separator
(1)High intensity magnetic field. The magnetic separator uses the Nb-Ti superconducting material to be the coil. The central magnetic intensity can reach 5.5T.
(2)Big magnetic force. The surface of magnetic matrix can produce strong magnetic force and separate the weakly magnetic Impurities.
(3)Nonvolatile liquid helium. 1.5W/4.2K refrigerator continue to refrigerate and make the little volatile liquid helium become liquid in order to make the liquid helium in the magnet.
(4)Low power consumption. The superconducting magnetic separator use the cryogenic superconducting technology that the electric resistance of the coil can reach zero when it is in the superconducting state, it can save electricity about 90% than the normal conductors.
(5)The magnet has a long service life (above 20 years).
(6)The two canisters work alternately for separation and discharge. It can work continually.
(7)Use the high temperature superconducting current lead, reducing heat loss.
(8)Full computer control, parameter real-time data acquisition. It’s good for production control and quality control.
(9)The 15t weight of the whole machine is the 1/6 of the electromagnetic separator in the same efficiency.

On June 30, 2012, the world's first nonvolatile 5.5t cryogenic superconducting Magnetic Separator passed the identification of the Organization of the Office of Science and Technology in Shandong Province and reached the international advanced level.

Standard export package in wooden cases, standard container, flat rack container or pack according to the requirements of customers.
Arrange the delivery around 45 days after receipt of the advanced payment.

One year quality guarantee.
Engineers are available to serve the machinery overseas.
