high intensity wet magnetic separator for concentrating Iron Ore:LHGC Vertical high gradient magnetic separator
- 30 Set / Sets per Month
- any port in China
- T/T
You May Like
-
Series JCTN---The Concentrate Upgrading Drum Permanent Magnetic Separator
-
Series JCTN--The Concentrate Upgrading Drum Permanent Magnetic Separator
-
Series JCTN: Raising Concentrate Grade and Decreasing Dregs Content Drum Permanent Magnetic Separator
-
Series JCTN - The Concentrate Upgrading Drum Permanent Magnetic Separator
-
Experimental Equipment - RCG&DDC Drum Permanent Magnetic Separator JCTN63
-
Series JCTN The Concentrate Upgrading Drum Permanent Magnetic Separator
Product Details
| Condition | New | Type | Magnetic Separator | |
| Production Capacity | As you required | Place of Origin | Shandong, China | |
| Brand Name | HUATE | Model Number | kinds of models | |
| Voltage | As you required | Power(W) | As you required | |
| Dimension(L*W*H) | As you required | Weight | 2~175 tons | |
| Certification | ISO/CE | Warranty | one year | |
| After-sales Service Provided | Overseas service center available |
Product Description
Specifications
1 For week magnetic metal ore2. Ring diameter: 500~3000 mm
3. Magnetic intensity: 11000
4. Capacity: 0.05~250 T/H
LHGC vertical ring high gradient magnetic separator
1.Global Third -generation Vertical Ring High Gradient Magnetic Separator(Forced Oil Cooling Circulation)
Advantages:
With advance structure, easy maintenance and reliable operation, good performance, wide applicability to ore granularity, ore density and ore grade which realize the goal of good concentration and good reclamation.
2.Global Fourth-generation Vertical Ring High Gradient Magnetic Separator(Oil-water Complound-cooling)
Application:
It can be used in wet processing -1.2 mm(-200 mesh of 30~100%) red ore (hematite and limonite, siderite etc.), manganese ore, ilmenite, chromite, tungsten ore and other kinds of weakly magnetic minerals and metallic minerals, such as quartz, feldspar, nepheline ore, kaolin for removing impurity iron and purification.
Model:
| Model | Diameter of revolving | Feeding size (mm) | Feeding density | Processing | Rated background | Rated exciting | Motor | Water | Water | Weight of main engine(t) | Appearance size |
| Ring(mm) | (%) | Capacity | Field intensity | Power | Power | Pressure | Consumption | L*W*H | |||
| (t/h) | (T) | Kw | Kw | MPa | m³/h | (mm) | |||||
| LHGC-500 | 500 | -1 | 10-40 | 0.1-0.3 | 1.1 | 16 | 0.37+0.18 | 0.1-0.2 | 0.75-1.5 | 1.5 | 1800*1400*1320 |
| LHGC-750 | 750 | -1 | 10-40 | 0.1-0.5 | 1.1 | 21 | 0.75+0.55 | 0.1-0.2 | 1.5-3.0 | 3 | 2000*1360*1680 |
| LHGC-1000 | 1000 | -1.2 | 10-40 | 3.5-7.5 | 1.1 | 30.8 | 2.2+1.1 | 0.2-0.4 | 10~20 | 6 | 2700*2000*2400 |
| LHGC-1250 | 1250 | -1.2 | 10-40 | 1.1 | 37.8 | 2.2+1.5 | 0.2-0.4 | 20-50 | 14 | 3200*2340*2700 | |
| LHGC-1500 | 1500 | -1.2 | 10-40 | 20-30 | 1.1 | 46.2 | 4+3 | 0.2-0.4 | 50-100 | 20 | 3600*2900*3200 |
| LHGC-1750 | 1750 | -1.2 | 10-40 | 30-50 | 1.1 | 65.3 | 4+4 | 0.2-0.4 | 70-160 | 35 | 3900*3300*3800 |
| LHGC-2000 | 2000 | -1.2 | 10-40 | 50-80 | 1.1 | 78.3 | 7.5+5.5 | 0.2-0.4 | 100-200 | 50 | 4200*3550*4200 |
| LHGC-2500 | 2500 | -1.2 | 10-40 | 80-150 | 1.1 | 96.3 | 11+11 | 0.2-0.4 | 200-400 | 105 | 5800*5000*5400 |
| LHGC-3000 | 3000 | -1.2 | 10-40 | 150-250 | 1.1 | 103.6 | 15+11 | 0.2-0.4 | 300-500 | 150 | 7600*6500*7200 |
wooden cases/steel frame,or according to the customer's requirements. Fumigation packaging!
12 monthes after-sale service. Best quality with easy maintainess.
Compang name:Shandong Huate Magnet Technology Co.,Ltd.
Address: Huate Road,Linqu Econonmic Development Area, Weifang City, Shandong Province, China.
Tel:0086-536-3391868 Contact person: Ms.Anna Wu
