Semi-electric Stacker SPN10/SPN20
- shanghai
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Shanghai, China | |
| Brand Name | cheuk's | Model Number | SPN10/SPN20 | |
| Type | Other, Semi-electric Stacker | Power Souce | AC Motor | |
| Rated Loading Capacity | 1T/2T | Max. Lifting Height | 3M/1.6M | |
| Min. Lifting Height | 85mm | Fork Length | 900/1100MM | |
| Fork Width | 150mm | Overall Dimensions | Pls Check | |
| Certification | CE/ISO9001 | After-sales Service Provided | No overseas service provided |
Product Description
The Specification of Semi-electric Stacker SPN10/SPN20
1KG=2.2LB 1INCH=25.4MM
Model |
| SPN10 | SPN20 |
| Capacity Q | Kg | 1000 | 2000 |
| Min.fork height h2 | mm | 85 | 85 |
| Max.fork height h3 | mm | 1600/2500/3000 | 1600 |
| Min.mast height h1 | mm | 1980/1830/2080 | 1980 |
| Size of fork e*s | mm | 150/160x60 | 150/160x60 |
| Length of fork l | mm | 900/1100 | 900/1100 |
| Width overall forks(Adjust/fixed)b5 | mm | 330~640/550 | 330~640/550 |
| Radius of gyration Wa | mm | 1240 | 1360 |
| N.W. | kg | 396/443/466 | 500 |
| Fork rollers l | mm | Φ74x70 | Φ74x70 |
| Big wheel | mm | Φ180x50 | Φ180x50 |
| Battery V/Ah (5 h autonomy) | 12/150 | 12/150 | |
| Lifting motor power(kw) | 1.5 | 1.5 |
Shanghai Cheuk's Logistics Technology Co., Ltd.,which is subordinate to Cheuksgroup, is specializing in the developing, manufacturing and marketing of logistics, lifting and hydraulic machinery. We have abundant product line, forklift truck, pallet truck, stacker, table lift, tail gate, tow trackor, aerial work platform,plastic hand truck, hydraulic tools and so on.
Our sales and network covers all over the world, also R&D center in Germany and America. We keep a really good relationship with our abroad partners. We based in China, supply you with our standard products of reliable quality, reasonable price. Also,the OEM service is available according to your requirements. Give us an opportunity, we will "Lifting your future"!
