TC Shape Purling Forming Machine for construction

FOB Price

USD $10 - $100,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Liaoning, China		Brand Name	PRO
Model Number	PRO		After-sales Service Provided	Engineers available to service machinery overseas

C Shape Purling Forming Machine for construction

Main Technical Specification
Size:	8500mm x1800mmx1800mm
Total weight: about	13000KG
Controlling system:	PLC
Main motor power:	15KW
Hydraulic station power:	15KW
Working speed:	13000mm/min
Hydraulic pressure:	18~20mpa
Product range:	All the types from 80 to 250
Feature and Usage
1. All the rollers are forged from the high quality structural steel and are processed intensely. The surfaces of the rollers are plated with hard chromium, which lengthens the operating life of rollers. 2. The computer controls the length, punching and counting. 3. There are the flattening rollers at the front end of the machine, which are used for flattening the strip steel with poor flatness. After flattening, the product is smoothing and flattening and conforms to the standard, which increases the economic benefit. 4. The C-shaped purling formed by this machine have excellent anti-bending property and are easy to install. 5. They are widely used as the supporter of roof and wall in large-scale and mid-scale construction, such as factory, warehouse, garage, gymnasium, exhibition center, cinema, theatre, garden, etc.
