Cast Steel Slide Valve
- Ningbo/Shanghai
- T/T D/P D/A
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | Gate | |
| Pressure | Medium Pressure | Power | Manual | |
| Material | Casting | Temperature of Media | Medium Temperature | |
| Media | Water | Port Size | DN6-DN700 | |
| Place of Origin | Zhejiang, China | Model Number | Z41H-300LB | |
| Brand Name | Dongjin |
Product Description
Specifications
1.Cast steel slide valve2.material: carbon steel
3.package: wooden box
4.payment: L/C, T/T
5.certificate: ISO 9001:2008,CE
|
|
|
Cast steel slide valve
Features |
| Specifications | |
OS & Y, Rising Stem |
| Design | ASME B16.34/API 600 |
Bolted Bonnet |
| Face to Face | ASME B16.10 |
Flexible Wedge (2" Solid) |
| End Flange | ASME B16.10 |
Extended Bonnet for |
| End to End | ASME B16.5/B16.47 |
Cryogenic Services |
| BW End | ASME B16.25 |
By Pass On Request |
| Test | API 598 |
Locking Device Optional |
| Special | NACE MR-01-75 |
Standard Materials of Main Parts | ||
ITEM | PART NAME | MATERIAL |
1 | Body | ASTM A216 GR.WCB |
2 | Seat Ring | ASTM A105 + Stellite Faced |
3 | Disc | ASTM A216 GR.WCB+13Cr Faced |
4 | Stem | ASTM A182 GR.F6 |
5 | Gasket | Soft Iron+Graphite |
6 | Bonnet | ASTM A216 GR.WCB |
7 | Bonnet Bolt Nuts | ASTM A194 GR.2H |
8 | Bonnet Bolts | ASTM A193 GR.B7 |
9 | Backseat Bushing | ASTM A276 Type 410 |
10 | Stem Packing | Braided Graphite & |
11 | Eye Bolt Pins | Die formed Graphite Ring Carbon Steel |
12 | Gland Eye Bolts | ASTM A307 GR.B |
13 | Gland | ASTM A276 Type 410 |
14 | Gland Flange | ASTM A216 GR.WCB |
15 | Eye Bolt Nuts | ASTM A194 GR.2H |
16 | Grease Nipple | Carbon Steel |
17 | Stem Nut | ASTM A439 GR.D-2 |
18 | Retaining Nut | Carbon Steel |
19 | Handwheel | Ductile Iron |
20 | Handwheel Nut | Carbon Steel |
21 | Screw | Carbon Steel |
22 | Yoke | ASTM A216 GR.WCB |
23 | Yoke Pan Bolt Nuts | ASTM A194 GR.2H |
24 | Yoke Pan Bolts | ASTM A193 GR.B7 |
25 | Bearing | Steel |
26 | Lantern Ring On Request | ASTM A276 Type 410 |
Cast steel slide valve
