LIYU SC-E series Graph Plotter

1. High quality Aluminum stands, more durable and Steady, high-grade.

2. Blue & Yellow backlight LCD, more clear and bright.

3. USB 2.0 interface, support hot-swappable.

4. Inertial rotating blade holder enables more accurate and high quality cutting.

5. Digital force & speed adjustable, direct and steady.

6. Auto. memory of blade force & Speed, adjustable at any time, easy to use.

7. Emergency stops & stops to return at any time to monitor the cutting quality, easy to operate.

8. Bulk copy up to 99, saving time and strength.

9. Unique red cutting slot, elegant, easy to operate.

MODEL

SC400

SC631E

SC801E

SC1061E

SC1261E

Drive Motor

Sepecial Stepper Motor

Media Size

470mm/1.54ft

710mm/2.33ft

880mm/2.89ft

1120mm/3.67ft

1340mm/4.40ft

Cutting Size

390mm/1.28ft

630mm/2.07ft

800mm/2.62ft

1040mm/3.41ft

1260mm/4.13ft

Max.Cutting Speed

400mm/s

Cutting Force

10~400g

LCD

With

Buffer capacity

1Mb

Resolution

0.025mm/step(0.001in./step)

Repeatability

0.127mm/0.005in.

Commands Set

HPGL or DMPL

Interfaces

Serial, USB optional

Positioning Mode

Origin Setup atrandom available

Copy Function

Up to 99 copies

Power

<100W

Power requirementst

AC220V/110V,50Hz~60Hz

Windows Driver

Direct Output from CorelDraw

Packing Size (WXDXH)

0.8X0.36X0.4m

(0.62X1.18X1.31ft)

1.04X0.36X0.4m

(3.41X1.18X1.31ft)

1.19X0.36X0.4m      (3.90X1.18X1.31ft)

1.43X0.36X0.4m        (4.69X1.18X1.31ft)

1.64X0.36X0.4m       (5.38X1.18X1.31ft)

G./Weight

14KG/31lbs

20KG/45lbs

25KG/55lbs

32KG/70.4lbs

39.0KG/86lbs

Environment

Temperature:035,  5%-95%Non-condensing
