Shanghai Horizon Xb-Zn360plus Adsorption Double Blade Die Cutting Machine

Display mode: 5-inch full touch operation interface

Material placement range: Width: 210-370mm, 297-750mm

Number of blade heads: Double blade heads

Knife and bell tools: carving knife, indentation

Mechanical accuracy: 0.01mm

Fastest cutting speed: 1600mm/s

Maximum pressure: 1000g

Minimum cutting pattern: 5mm diameter circle

The thickest material that can be cut weighs 350g

Feeding time: about 4 seconds

Transmission methods: Ethernet cable, WiFi, USB flash drive, USB data cable

Paper capacity: 12 centimeters (approximately 1000 sheets)

Language: Chinese, English, Spain, Denmark, Türkiye, Hungary

Voltage: Supports 110V/220V (automatic voltage conversion)

Operating software: AI (CS6-2023), Coreidraw (x4-x8.2017-2023) (continuously updated)

Operating environment: Temperature: 10 ° C to 35 ° C Humidity: 35 to 75% RH

Computer system: Windows 7-10, Apple operating system

Dimensions (mm): Non unfolded dimensions: Length 790mm, Width 800, Height 1230

(Length X Width X Height): Unfold size: Length 1420mm, Width 800, Height 1230

Gross weight: approximately 182kg (total volume converted to approximately 210kg)

Packaging dimensions: length 970mm, width 950mm, height 1390mm

Intelligent lifting platform:

The adsorption type adopts a large capacity intelligent lifting platform, which can hold 12 centimeters of material (about 1000 sheets). Save frequent paper placement time and improve work efficiency

Save labor. Adopting an automatic paper feeding design with upward suction, vacuum suction system, anti double sheet function for paper retraction, widened suction belt for smoother paper feeding

Effectively reduce the issues of double sheets and paper jams. Can adapt to cutting various materials. Equipped with a large capacity paper tray design, paper delivery is more convenient.

Double blade design:

Adopting a dual blade design, it can simultaneously complete half cutting, full cutting, point line, indentation, and other tasks in one go without the need for secondary paper feeding. At the same time, both blades use independent voice coils

Motor control allows for independent cutting and indentation, resulting in more precise control of cutting force and more stable cutting and indentation effects. Double Knife Picking

By using an independent voice coil motor, the service life is longer, improving the indentation cutting effect while effectively reducing the failure rate.

High performance servo motor:

The operation is controlled by high-precision overspeed servo motors, which provide faster speed, higher accuracy, quieter sound, better stability, and more precise control. speeding

The servo motor achieves closed-loop control of position, speed, and torque; Avoiding the problem of step loss during long-term operation of stepper motors, it is suitable for occasions with high-speed response requirements.

High stability crossbeam:

Adopting high-precision crossbeam design, the guide rails are all made of aluminum and steel running structure, and the trolley adopts a lightweight all aluminum structure with eight points

The support is fixed, and the support points are all supported by steel bars for operation. It is not easy to deform and wear out after long-term operation. The car uses P5 level bearings for operation,

Durable and high-precision crossbeams greatly improve the operational accuracy and stability of the machine, ensuring that it operates at high speeds,

No shaking, better stability

High precision car:

The cutting process is controlled by a voice coil motor, which has high precision, high speed, and faster response speed,

Durable, wear-resistant, and have a long service life. This way, the cutting force of the material is more accurately and stably controlled, and it is less likely to have depth or depth

Inconsistencies ensure the qualification rate of finished products, effectively prevent material waste, and achieve unmanned operation

High resolution CCD camera:

Adopting high-resolution CCD high-definition camera for precise detection of marked points (compatible with corner lines and circles), and can

Accurately detect marked points on colored and reflective materials. Layout can be customized according to customer needs to save materials and reduce production costs

It can also support brightness adjustment of lights, allowing for free adjustment of light brightness according to different materials, increasing recognition accuracy

QR code system:

It can automatically read the QR code printed on the material, just add the QR code when making the file and print it out

Code file, the machine will automatically read the QR code file and accurately cut it, which can effectively reduce the time of searching for files and improve efficiency

work efficiency. It can also support reading network QR codes. When creating QR code files, save the files to the specified location

In the computer folder, select QR code reading in the plugin, and the machine will automatically read the specified QR code folder and search for the QR code automatically

Perform precise cutting to improve work efficiency,

Intelligent software:

The operating software adopts CDR, AI+plugin mode, with one click generation of corner lines and dot shaped marking points, dual marking point recognition, and plugins based on

Paper size and content automatically generate marked points, one click typesetting, one click contour generation, software automatically optimizes cutting paths, making it convenient for users to operate,

Simple and efficient, improving user work efficiency. At the same time, the machine optimizes the paper rolling method. When the paper rolling fails, it will automatically return the paper and repeat the feeding process three times

Ensure smooth paper feeding

Multiple transmissions:

The operating software adopts Ethernet cable, WIFI, USB flash drive, and USB data cable for remote control, and can support one computer to connect multiple machines for synchronous sending

Operation, up to 100 machines can be connected simultaneously, or one machine can be remotely sent from multiple computers, and each computer can send operations separately

Make a machine without the need for specialized computer operation. For graphic and text advertising stores, the machine position can be placed freely and can be remotely sent through a network port or WIFI for operation

Connecting the machine with a traditional USB data cable is more convenient to use. You can also operate offline using a USB flash drive without using a network or USB cable. pass

Printer, prints marking points and patterns, automatically feeds, locates, cuts, and outputs paper, achieving automated operation.

Humanized functional design:

There is a counting and skipping recording function inside, so when users put in a large amount of materials to the machine for cutting, they do not need to look at the machine at this time

After the machine cutting is completed, there will be a count. If there is any material that fails to scan halfway, the machine will automatically dispense the material and record the number of copies in the settings

Scanning failed, users only need to check the number of skipped copies after the machine cutting is completed to determine if there is a problem with the cutting, saving customers time

The unmanned operation of machines has emerged. improve work efficiency

High quality materials:

The motherboard chip adopts ST imported chips, which have high performance, low power consumption, durability, and excellent stability. X. Y running belt

Adopting imported pioneer belts, it has good transmission stability, higher precision, durability, and very strong stability. Using Sharp sensors for sensitive sensing

High temperature, long lifespan, and the status of the sensor can be observed in the machine settings, making it convenient for users to identify and promptly repair problems when they occur.

The paper feeding adopts a thickened stopper gauge with a thickness of 9 millimeters, which ensures that the stopper is not easy to loosen and the paper is not easily skewed when feeding in large quantities

Stability
