Home > Products > Motherboard > ITX-N29_18 12*12 with Baytrail Motherboard, Dual Lan Quad Core Mainboard J1800,J1800 nano itx motherboard OEM
ITX-N29_18 12*12 with Baytrail Motherboard, Dual Lan Quad Core Mainboard J1800,J1800 nano itx motherboard OEM
- 30000 Piece / Pieces per Month
- ShenZhen
- T/T Credit Card PayPal
You May Like
-
ITX-N29_19 Fanless J1900 NANO Motherboard,Fanless Motherboard DC12V,Fanless Motherboard
-
ITX-N29_2L with 12*12 Bay trail Dual Lan Quad Core Mainboard J1900 nano itx motherboard OEM
-
ITX -N29 Baytrail Motherboard with Lan Quad Core Mainboard J1900,J1900 nano itx motherboard OEM
-
4 gigabit Bay trail SOC J1800 MINI ITX 4 LAN Motherboard for Firewall Router
-
4 ethernet ports motherboard J1900 fanless J1900 2.5' HDD inboard with BYPASS supported/ High performance Router Motherboard
-
Server Motherboard fanless Bay Trial Platform Quad Core J1900 and USB3.0 Fanless Mini ITX 4 LAN Ports Motherboard
Product Details
| Products Status | Stock | Form Factor | Mini-ITX | |
| Memory Type | DDR3 | Hard Drive Interface | SATA | |
| Brand Name | INCTEL | Model Number | ITX-N29_18 | |
| Place of Origin | Guangdong, China | FSB / HT | 2 GHz |
Product Description
1. ITX-N29_18 front view
Integrated Intel® Celeron J1800 latest Bay Trail platform dual-core clocked up to 2.41Ghz 4CPU maximum pulse frequency of up to 2.58Ghz
2. ITX-N29_18 motherboard side view
Cooling fanless cooling, thereby achieving zero noise cooling
3. ITX-N29_18 motherboard side view
4. ITX-N29_18 motherboard side
5. ITX-N29_18 rear view
6. ITX-N29_18 side view
Item No. | ITX-N29_18VER:1.3 |
CPU | Integrated Intel® Celeron Processor J1800 2.41GHz |
| Compatible with Intel® Bay Trail -I/M/D full series CPU |
Chipset | Intel® Bay trail SOC Platform, CPU integrates chipset |
Memory | 1* SO DDRIII 1333/1066 ,up to 8GB |
Display | Integrated Intel® HD Graphics |
| Support VGA ,HDMI/LVDS synchronous/asynchronous display |
Expansion Slot | 1* Mini-PCIE ,support WIFI/3G |
| 1* mSATA, support wifi/SSD (default SSD) |
Lan | 2* RTL8111E Gigabit Lan ,Support wake-on-line ,PXE |
Storage | 1* SATA |
Audio | Integrated Realtek HD ALC662 for 6-Channel output,support MIC & Line-out |
Front Panel | 1* MIC(Red) |
1* SIM Card | |
1* COM(CISCO , RJ45) | |
2*USB (1* USB 2.0 ;1*USB3.0) | |
1* HDDLED | |
1* POWER | |
Back I/O | 1* 12V DC_JACK Input |
1* HDMI | |
1* VGA | |
2* LAN | |
1* Line-out(Green) | |
Internal I/O | 1* JVGA1 12pin |
1* RS232 | |
2* USB 2.0 | |
1* PS/2 6Pin | |
1* FP1 2*5pin Front panel buttons and LED connected | |
1* AUDIO Front Audio interface 2*5pin | |
2* Speaker 2pin | |
1* PWROUT (Hard drive power connector) | |
1* ATX 4pin | |
FAN | 1* CPU FAN 4pin , with smart temperature control fan |
GPIO | Support 4 way Input & Output GPIO |
BIOS | AMI 32MB Flash ROM |
Watch Dog | Support hardware reset function (L256, 0~255 seconds) |
Power | DC_12V Single power supply |
Operating Temp. | -10°C~60°C |
Storage Temp. | -20°C~80°C |
Humidity | 5%-95% ( relative humidity; non-condensing) |
Size | 120mm x 120mm |
