2P3TSub-Mini Pushbutton Toggle Switch
US$ 0.6 - 0.7
/ Piece
1000 Pieces(Min. Order)
- ShenZhen OR HongKong
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Ganhad | |
| Model Number | SMPS-2COA4 | Max. Current | AC .1.5A 250V | |
| Max. Voltage | AC 3A 250V | Mechanical Life | 200000 Cycles |
Product Description
Specifications
The product is high Quality Material, Have a long life.and the price is ply with ROHS/HF .Specification:
Contact Rating: 1.5A 250V AC: 3A 125V AC
Current Resistance : 20mΩ Max
Insulation Resistance : 500V DC 1000mΩ Min
Dielectric Strength : 1500V AC,1 Minute
Operating trmperature : -55°C--+85°C
Electrical life : 20000 Cycles
Housing : PBT UL94V-0
Terminals: Silver-plated Brass
...
