Home > Products > Toggle Switch series > Sub Miniature Rocker and Lever Handle Switch&twin Rocker Switch of ON OFF
Sub Miniature Rocker and Lever Handle Switch&twin Rocker Switch of ON OFF
- HK OR SHENZHEN
- T/T
You May Like
Product Details
| Brand Name | Ganhad | Model Number | SRLS-102-A1 | |
| Max. Current | 1.5A 250V AC | Max. Voltage | 3A 125V AC | |
| Mechanical Life | 20000 |
Product Description
Specifications
The use of new materials production, has high reliability, Long service life,low consumption.Specification: Contact Rating: 1.5A 250V AC: 3A 125V AC Current Resistance : 20mΩ Max Insulation Resistance : 500V DC 1000mΩ Min Dielectric Strength : 1500V AC,1 Minute Operating trmperature : -55°C--+85°C Electrical life : 20000 Cycles Housing : PBT UL94V-0 Terminals: Silver-plated Brass
|

...
Contact Us
- Shenzhen Ganhad Plastic Electronics Co., Ltd.
- Contact namechris shi Chat Now
- Phone86-755-23249715
- AddressNo. 278, Huafa North Road, Shangnian New Village, Gongming Office, Guangming New District, Dongguan, Guangdong
