YHRSMST/A Heat shrikable molded parts
Negotiable
/ Piece
1000 Pieces(Min.Order)
- 10000 Piece / Pieces per Month
- Dalian
- T/T
You May Like
Product Details
| Place of Origin | Liaoning, China | Brand Name | UPM | |
| Model Number | YHRSMST/A | Type | Heat Shrinkable | |
| Material | PVC |
Product Description
Specifications
1.Shrink ratio: 4:1 (at small end)2.Flame Resistant: with OI (Oxygen Index) higher than 27
3. Abrasion resistant
YHRSMST/A Heat Shrinkable Molded Parts
Voltage Class 1kV Ideal for strain relief and mechanical protection of cable harness assemblies
Molded heat shrinkable parts for cable harness assemblies, commonly used for insulation, mechanical protection and seal against water and other contaminants.
Applications
Strain relief and mechanical protection of cable harness assemblies used in lamps, electricity supply module for motor, switch board or other electrical equipments that are installed in sea-going vessels, offshore oil platform, shipyard or harbour
Other electrical cable joints which require water sealant and mechanical protection
Features/Benefits
Shrink ratio: 4:1 (at small end)
Flame Resistant: with OI (Oxygen Index) higher than 27
Abrasion resistant: made from semi-rigid materials
Adhesive-lined, sealing against water, moisture and/or other contaminants
Temperature Range
Operating Temperature : -40 ~ 90 oC
Shrink Temperature : 135 oC
Colour:Black
Certification
CCS type approved
Product Code Cross References
Raychem : 202A111~202A196
Technical Details
Test Item | Test Method | Typical Value |
expansion strength | ASTM D2671 | ≥ 10Mpa |
break out elongation | ASTM D2671 | ≥ 350% |
expansion strength after aging | ASTM D2671 | ≥ 10Mpa |
break out elongation after aging | ASTM D2671 | ≥ 300% |
dielectric strength | ASTM D149 | ≥ 14kV/mm |
Flammability | ASTM D2863 | Oxygen Index ≥27% |
water absorption | ASTM D570 | ≤ 0.5% |
peel off adhesive to PEX | ASTM D2671 | ≥ 30N/cm |
peel off adhesive to steel | ASTM D2671 | ≥ 30N/cm |
Product Selection
| Item | Corre- sponding Mil. No. | Before heat shrink (a) | After heat shrink (b) | Total length (P) | Big end length (R) | Small end length (JO) | Thickness | ||
| H Big end | J Small end | H big end | J Small end | ±20% (b) | ±20% (b) | ±20% (b) | ±10% (b) | ||
| B0 | 202A111 | 16.5 | 16.5 | 8.5 | 4 | 25 | 14 | 6 | 1.5 |
| B1 | 202A121 | 24.6 | 24.6 | 10 | 6 | 35 | 20 | 10 | 1.6 |
| B2 | 202A132 | 28.4 | 28.4 | 15 | 7 | 50 | 25 | 15 | 1.8 |
| B3 | 202A142 | 31.0 | 31.0 | 19 | 8 | 65 | 35 | 20 | 1.8 |
| B4 | 202A153 | 36.1 | 36.1 | 23 | 9 | 90 | 45 | 35 | 1.8 |
| B5 | 202A163 | 42.7 | 42.7 | 29 | 10 | 100 | 55 | 35 | 2.0 |
| B6 | 202A174 | 60.0 | 60.0 | 38 | 16 | 120 | 60 | 40 | 3.3 |
| B7 | 202A185 | 66.0 | 66.0 | 45 | 20 | 135 | 80 | 40 | 3.3 |
| B8 | 202A196 | 86.4 | 86.4 | 59 | 28 | 170 | 95 | 55 | 3.3 |
Ordering
When ordering this product, please specify 1) Product code 2) Colour 3) Quantity Required
