VW-1 Kynar thin wall heat shrink tube
- 10000 Meter / Meters per Month
- Dalian China
- T/T
You May Like
Product Details
| Place of Origin | Liaoning, China | Brand Name | UPM | |
| Model Number | S5 PVDF | Type | Insulation Sleeving | |
| Material | Other, Composite Polymer, PVDF | Application | Low Voltage | |
| Rated Voltage | 1kV | Tensile Strength | >35Mpa |
Product Description
Specifications
1.Semi-rigid, cross linked thin wall PVDF2.Abrasion resistance
3.Chemical and solvent resistance
4.VW-1 high flame retardant
S5 PVDF Heat shrinkable tubing
1.Semi-rigid, cross linked thin wall PVDF
2.Abrasion resistance
3.Chemical and solvent resistance
4.VW-1 high flame retardant
Ideal for hight temperature protection and see-through inspection
Semi-rigid, high abrasion resistant and anti-corrosion heat shrinkable tubing designed for electronic, automotive,military and other applications requiring 150 degree or 175 degree high temperature protection, insulation and see-through inspection
Features/Benefits
1)Shrink ratio: 2:1
2)Designed for applications requiring high temperature resistance(150 degree or 175 degree)
3)Semi-rigid insulation tubing
4)Excellent chemical and solvent resistance
5)Flame retardant meets UL-224 VW-1 standard
6)Extremely tough, providing mechanical and abrasion protection, and strain relief
7)Transparent tubing for easy see-through inspection
8)Ideal for electronic, automotive, military and other applications requiring protection and insulation in aggressive environments
Temperature range
1) Operating temperature: -55 degree to 175 degree
2) Shrink temperature: 150 degree or 175 degree
Color: Transparent and Black
Technical Details
Test Item | Test Method | Typical Value |
Performance temperature range | IEC 216 | -55oC to 175 oC
|
Before aging: Tensile strength | ASTM D638 | Min. 35Mpa |
Before aging: Breakdown elongation | ASTM D638 | Min. 150% |
After aging: Tensile strength | 180oC for 168 hrs | No lower than 70% before aging |
After aging: Breakdown elongation | 180oC for 168 hrs | No lower than 70% before aging |
Heat resistance | 300oC/hr | No cracking |
Distortion | 150oC/hr | Max. 50% |
Low temperature resistance | -55oC for 4 hrs | No cracking |
Elasticity | 180oC for 168 hrs | No cracking |
Incision modulus | - - | Min. 84.4 Mpa |
Dielectric strength | ASTM D2671 | Min. 25kV/mm |
Volume resistivity | ASTM D876 | Min. 1013 Ω.cm |
Copper corrosion | 180oC for 168 hrs | No corrosion |
Copper stability | 180oC for 168 hrs | Stable |
Flame retardant | UL VW-1 | Pass |
Product Selection (Shrink Ratio 2:1)
Product Code | Internal Diameter Before Shrink/After Shrink | Minimum Wall Thickness After Shrink | Standard Length (m/roll) | ||
(mm) | (inch) | (mm) | (inch) | ||
S5-Φ1.2 | 1.2/0.6 |
| 0.20 | 0.008 | 200 |
S5-Φ1.6 | 1.6/0.8 |
| 0.20 | 0.008 | 100 |
S5-Φ2.4 | 2.4/1.2 |
| 0.23 | 0.009 | 100 |
S5-Φ3.2 | 3.2/1.6 |
| 0.23 | 0.009 | 100 |
S5-Φ4.8 | 4.8/2.4 |
| 0.23 | 0.009 | 1.22 |
S5-Φ6.4 | 6.4/3.2 |
| 0.28 | 0.011 | 1.22 |
S5-Φ9.5 | 9.5/4.8 |
| 0.28 | 0.011 | 1.22 |
S5-Φ12.7 | 12.7/6.4 |
| 0.28 | 0.011 | 1.22 |
S5-Φ19.0 | 19.0/9.5 |
| 0.40 | 0.016 | 1.22 |
S5-Φ25.4 | 25.4/12.7 |
| 0.40 | 0.016 | 1.22 |
Cross references:
Raychem/TYCO: rw-175/kynar
DSG Canusa: DERAY KY175
Sumitomo: K
3M: kYNAR
