Home > Products > Solar Connector & cable > 2016 REOO MC4,solar Connector Solar Power System Connector
2016 REOO MC4,solar Connector Solar Power System Connector
- Shanghai
- T/T
You May Like
-
2016 REOO RO - 1 T Branch Connector for Solar Power System,solar Connector
-
2.5mm2~6.0mm2 Solar PV Cable,suitable for Solar Power System,rated Current From 20A~140A
-
MC3 Connector Male and Female Adapter TUV Photovoltaic Connector
-
MC4 Solar Hand Crimping Tool for Solar Power Connector
-
HOT Sale MC4 Y TYPE PV Branch Solar Connector From REOO Solar
-
PV Junction Box REOO PV Junction Box Solar Junction Box
Product Details
| Place of Origin | Jiangsu, China | Brand Name | REOO | |
| Model Number | RO-1 | Specification | Normal | |
| Application | Industrial | Output Voltage (V) | 1000 | |
| Load Power (W) | 16KW | Solar Power (W) | 10KW | |
| Work Time (h) | 24hours |
Product Description
MC4 Solar power cable connector
Item | RO-1 solar cable connector |
Compatible: | MC4 solar connector |
Insulation material: | PC |
Rated current : | 30A |
Rated voltage: | 1500V |
Test voltage : | 6000V(50Hz,1Min) |
Contact material : | Copper Tin plated |
Contact resistance: | 5mΩ |
Degree of protection : | IP67 |
Safety class: | 2 |
Flame class: | UL94-V0 |
Insertion force : | ≤50N |
Withdrawal force : | ≥50N |
Ambient temperature range : | -40 degree to +90 degree |
Connector diameter : | 4mm |
Compatible cable cross sections : | solar cable 4.0mm2 and 6.0 mm2 |
Suitble cable : | 2.5-6.0mm2 AWG 14/12/10 |
Be used for: | Connecting PV cable |
characteristic | High insulation,Big tension,Fast integration |
REOO Connector use PC raw material, It is top quality.
Package
Male house | 100 pcs / PE bag. 10 bag / carton, also 1000 Pin/carton |
Female house | 100 pcs / PE bag. 10 bag / carton, also 1000 Pin/carton |
Measure | 380*290*470 mm/carton |
Net weight | 34 kg / carton |
Gross weight | 35.5 kg / carton |
| Mr Mike Xu
NANTONG REOO TECHNOLOGY CO.,LTD.
Add: Chennan industrial park, Rudong, Jiangsu,China
Tel: 86 513 8410 5399
Fax: 86 513 8410 5505
Skype: reoochina
WhatsApp: 86 1390 1472 859
Wechat: REOO2108 |
